Ford Flex I (2008-2013) drvr frt cr feed drvr frt cr rtn pass frt cr rtn pass frt cr feed wiring diagram

& 5-6, 7-8, 15-16, 17-18 ANTI-LOCK BRAKES SYSTEM BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE CASE GROUND CLOCKSPRING (STEERING COLUMN ASSEMBLY) COLLAPSIBLE STEERING COLUMN MODULE (CENTER OF DASH) COMPUTER DATA LINES SYSTEM DRIVER 1 SIDE IMPACT SENSOR (DRIVER'S DOOR) DRIVER 2 SIDE IMPACT SENSOR (LEFT "C" PILLAR) DRIVER AIR BAG MODULE (STEERING WHEEL) DRVR FRT CR FEED DRVR FRT CR RTN PASS FRT CR RTN PASS FRT CR FEED DRVR TRACK POS PASS BUCKLE SENS DRVR BUCKLE SW DRVR IM SN RTN DRVR IM SN FEED ENGINE CONTROLS SYSTEM ENS GRN/BLU WIRE GRN/ORG WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/YEL WIRE LEFT FRONT IMPACT SENSOR (BEHIND LEFT SIDE OF FRONT BUMPER) NCA WIRE ORG GRY/ WIRE ORG/ WIRE PAD INDICATOR PASSENGER 1 SIDE IMPACT SENSOR (FRONT PASSENGER'S DOOR) PASSENGER 2 SIDE IMPACT SENSOR (RIGHT "C" PILLAR) PASSENGER AIR BAG MODULE (RIGHT SIDE OF DASH) PASSENGER SAFETY CANOPY MODULE (TOP OF RIGHT "D" PILLAR) PTS ADAPTIVE FEED PTS ADAPTIVE RTN RED WIRE RESTRAINTS CONTROL MODULE (RCM) (CENTER CONSOLE) RIGHT FRONT IMPACT SENSOR (BEHIND RIGHT SIDE OF FRONT BUMPER) RUN/START SHORTING BAR SHORTING BAR SHORTING BAR STAGE 1 STAGE 2 VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE
