Ford Flex I (2008-2013) driver unlock relay Wiring diagrams

This page contains all the electrical diagrams for the component. driver unlock relay, in which he is found in the car Ford Flex I (2008-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram driver unlock relay (1 of 3)

Wiring diagram driver unlock relay for Ford Flex I (2008-2013)

Get access

ACCESSORY DELAY RELAY ALL LOCK, UNLOCK RELAY AUTO BLK WIRE BLK/BLU WIRE BLU WIRE BLU/GRN WIRE BRN WIRE DRIVER SIDE DOOR LOCK SWITCH DRIVER UNLOCK RELAY FUSE 17 FUSE 41 GRN WIRE GRY WIRE GRY/BRN WIRE HEADLIGHTS SYSTEM HORNS SYSTEM HOT AT ALL TIMES LEFT REAR DOOR LOCK ACTUATOR (REAR OF LEFT REAR DOOR) LOCK LOGIC LR DOOR AJAR MICRO - PASS TRIM DOOR LOCK AJAR PASSENGER SIDE DOOR LOCK SWITCH PASSENGER SIDE FRONT DOOR LOCK UNIT (REAR OF FRONT PASSENGER'S DOOR) POWER DISTRIBUTION SYSTEM RIGHT REAR DOOR LOCK ACTUATOR (REAR OF RIGHT REAR DOOR) RR DOOR AJAR SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) TO LIFTGATE REL FET (DIAGRAM 2 OF 2) TRIM HORN UNLOCK RLY UNLOCK VIO WIRE WHT WIRE YEL WIRE YEL/VIO WIRE

Go to component -> Forced entry circuit (1 of 2) -> DRIVER UNLOCK RELAY

Wiring diagram driver unlock relay (2 of 3)

Get access

ACCESSORY DELAY RELAY ACCESSORY PROTOCOL INTERFACE MODULE (FPIM) (W/ SYNC) ALL LOCK, UNLOCK RELAY AMBIENT AMBIENT PASSENGER LIGHTING LIGHTING SIDE DOOR MODULE SWITCH LOCK SWITCH AUTO ROOF DIMMING OPENING INTERIOR PANEL MIRROR MODULE UNIT BACK LIGHTING LED (FET) BLU WIRE BLU/RED WIRE BOX (SJB) (LEFT SIDE OF DASH) BRN/RED WIRE CIRCUIT BREAKER 47 CLOCK FRONT DISPLAY INTERFACE MODULE (FDIM) CONTROL MODULE DATA LINK CONNECTOR (DLC) DRIVER SIDE DOOR LOCK SWITCH DRIVER SIDE INSTRUMENT FRONT SEAT CLUSTER (IC) CONTROL SWITCH (W/ MEMORY SEATS) DRIVER UNLOCK RELAY FOG LAMP RELAY FROM FUSE 18 (DIAGRAM 3 OF 4) FROM FUSE 8 (DIAGRAM 1 OF 4) FRONT CONTROL INTERFACE MODULE (FCIM) FRONT HEATED SEAT MODULE FUSE 10 FUSE 11 FUSE 14 FUSE 15 FUSE 16 FUSE 17 FUSE 18 FUSE 19 FUSE 20 FUSE 21 FUSE 22 FUSE 23 FUSE 24 FUSE 26 FUSE 41 FUSE 6 FUSE 7 FUSE 8 GRN/BLU WIRE GRN/RED WIRE HIGH BEAM PARK LAMP RELAY RELAY HORN RELAY HVAC MODULE LEFT LOW BEAM (FET) LEFT SECOND ROW POWER FOLD SEAT MOTOR LF TURN LAMP (FET) LIFTGATE REL (FET) LIFTGATE/ TRUNK MODULE (LTM) LR STOP/ TURN LAMP (FET) MASTER WINDOW CONTROL SWITCH MICRO - PASSENGER LEFT REAR SIDE WINDOW WINDOW CONTROL CONTROL SWITCH SWITCH PUDDLE LAMP (FET) RED GRN/ WIRE RED YEL/ WIRE RED/ WHT WIRE RF TURN LAMP (FET) RIGHT LOW BEAM (FET) RIGHT REAR WINDOW CONTROL SWITCH RIGHT SECOND ROW POWER FOLD SEAT MOTOR RR STOP/ TURN LAMP (FET) SMART JUNCTION SMART JUNCTION BOX (SJB) TO FUSE 21 (DIAGRAM 3 OF 4) TO FUSE 40 (DIAGRAM 4 OF 4) VIO/RED WIRE W/ REAR FOLDING SEATS W/O NAVI- GATION W/O SYNC W/ SYNC WHT/RED WIRE YEL/RED WIRE

Go to component -> Power distribution circuit (3 of 4) -> DRIVER UNLOCK RELAY
