Ford Flex I (2008-2013) driver sunload Wiring diagrams

This page contains all the electrical diagrams for the component. driver sunload, in which he is found in the car Ford Flex I (2008-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram driver sunload (1 of 2)

Wiring diagram driver sunload for Ford Flex I (2008-2013)

Get access

AUTOLAMP/SUNLOAD SENSOR (CENTER OF DASH) AUTOMATIC A/C BLK WIRE BLK/BLU WIRE BLU/BRN WIRE BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER SUNLOAD FLASH TO HIGH PASS BEAM FOG LAMP RELAY FTP FUSE 21 GRN WIRE GRN/BRN WIRE GRY WIRE GRY/ORG WIRE HOT AT ALL TIMES HVAC MODULE (CENTER OF DASH) INSTRUMENT CLUSTER LEFT FRONT FOG LAMP MANUAL A/C MICRO - MS CAN + MS MS CAN CAN MULTI- FUNCTION SWITCH OFF ORG/ WIRE PARK BRAKE SW PARK BRAKE SWITCH (LEFT KICK PANEL) PASSENGER SUNLOAD RIGHT FRONT FOG LAMP SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) SOLID STATE SUNLOAD SENSOR (CENTER OF DASH) VIO WIRE VIO/GRY WIRE VIO/ORG WIRE WHT WIRE WHT/ORG WIRE WHT/VIO WIRE WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT) WIPER STATUS YEL WIRE YEL/ORG WIRE

Go to component: -> Headlights circuit, with high intensity gas discharge headlights (2 of 2) -> DRIVER SUNLOAD

Wiring diagram driver sunload (2 of 2)

Wiring diagram driver sunload for Ford Flex I (2008-2013)

Get access

AUTOLAMP/SUNLOAD SENSOR (CENTER OF DASH) AUTOMATIC A/C BLK WIRE BLK/BLU WIRE BLU/BRN WIRE BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER SUNLOAD FOG LAMP RELAY FUSE 21 GRN WIRE GRY WIRE GRY/ORG WIRE HOT AT ALL TIMES HVAC MODULE (CENTER OF DASH) INSTRUMENT CLUSTER LEFT FRONT FOG LAMP MANUAL A/C MICRO - MS CAN + MS MS CAN CAN ORG/ WIRE PARK BRAKE SW PARK BRAKE SWITCH (LEFT KICK PANEL) PASSENGER SUNLOAD RIGHT FRONT FOG LAMP SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) SOLID STATE SUNLOAD SENSOR (CENTER OF DASH) VIO WIRE VIO/GRY WIRE VIO/ORG WIRE WHT WIRE WHT/VIO WIRE WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT) WIPER STATUS YEL WIRE YEL/ORG WIRE

Go to component: -> Headlights circuit, without high intensity gas discharge headlights (2 of 2) -> DRIVER SUNLOAD
