Ford Flex I (2008-2013) driver door reset set keypad ajar sw sw Wiring diagrams

This page contains all the electrical diagrams for the component. driver door reset set keypad ajar sw sw, in which he is found in the car Ford Flex I (2008-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram driver door reset set keypad ajar sw sw (1 of 2)

Wiring diagram driver door reset set keypad ajar sw sw for Ford Flex I (2008-2013)

Get access

1/2 3/4 5/6 7/8 9/0 AJAR SET RESET BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLU WIRE BLU/GRN WIRE BLU/ORG WIRE BRN WIRE BRN/VIO WIRE DRIVER DOOR RESET SET KEYPAD AJAR SW SW DRIVER SIDE FRONT DOOR LOCK UNIT (REAR OF DRIVER'S DOOR) FROM FUSE 17 (DIAGRAM 1 OF 2) FUSE 13 GRN WIRE GRY WIRE GRY/BRN WIRE GRY/ORG WIRE HOOD AJAR HOOD SWITCH (LEFT FRONT CORNER OF ENGINE COMPT) HOT AT ALL TIMES KEYPAD ILLUM KEYPAD KEYPAD KEYPAD SWITCH ASSEMBLY LIFTGATE GLASS AJAR LIFTGATE LATCH ASSEMBLY (MANUAL LIFTGATE) (BOTTOM OF LIFTGATE) LIFTGATE REL (FET) LIFTGATE RELEASE SWITCH (MANUAL LIFTGATE) LIFTGATE SW LOGIC MICRO - NCA WIRE ORG/ WIRE RED WIRE RKE RECEIVER INTERNAL ANT SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Forced entry circuit (2 of 2) -> DRIVER DOOR RESET SET KEYPAD AJAR SW SW
