Ford Flex I (2008-2013) defogger defogger system system interior lights interior system lights system Wiring diagram

This page shows the only wiring diagram for the component.defogger defogger system system interior lights interior system lights system, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram defogger defogger system system interior lights interior system lights system (1 of 1)

Wiring diagram defogger defogger system system interior lights interior system lights system for Ford Flex I (2008-2013)

Get access

BLK WIRE BLK/BLU WIRE BLU/GRN WIRE BRN/BLU WIRE BRN/WHT WIRE DEFOGGER DEFOGGER SYSTEM SYSTEM INTERIOR LIGHTS INTERIOR SYSTEM LIGHTS SYSTEM DOWN EXTERIOR REAR VIEW MIRROR SWITCH FUSE 13 GRN/VIO WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT EXTERIOR REAR VIEW MIRROR (MIRROR ASSEMBLY) LEFT RIGHT LEFT/ RIGHT UP/ DOWN MIRROR SELECT RIGHT DOWN LEFT RIGHT EXTERIOR REAR VIEW MIRROR (MIRROR ASSEMBLY) RIGHT LEFT SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) UP DOWN VIO WIRE YEL/VIO WIRE

Go to component: -> Power mirrors circuit -> DEFOGGER DEFOGGER SYSTEM SYSTEM INTERIOR LIGHTS INTERIOR SYSTEM LIGHTS SYSTEM
