Ford Flex I (2008-2013) breakout to fuel injector 6) Wiring diagram
This page shows the only wiring diagram for the component.breakout to fuel injector 6), which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram breakout to fuel injector 6) (1 of 1)
A/C CLUTCH RELAY
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BREAKOUT TO FUEL INJECTOR 6)
BRN/GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CONTROL MODULE
CYLINDER HEAD TEMPERATURE SENSOR (TOP FRONT OF RIGHT CYLINDER HEAD)
EVAP CANISTER PURGE VALVE (RIGHT REAR OF ENGINE COMPT)
FUEL PUMP MOTOR DIODE
FUEL PUMP RELAY
FUSE 11
FUSE 27
FUSE 37
FUSE 46
FUSE 47
FUSE 48
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HEATED OXYGEN SENSOR
HOT AT ALL TIMES
HOT IN START OR RUN
PCM POWER RELAY
REVERSING LAMPS RELAY
TRANSDUCER)
VARIABLE CAMSHAFT TIMING (VCT) SOLENOID 1 (TOP FRONT OF RIGHT CYLINDER HEAD)
VARIABLE CAMSHAFT TIMING (VCT) SOLENOID 2 (TOP FRONT OF LEFT CYLINDER HEAD)
VIO WIRE
VIO/GRN WIRE
WHT WIRE
WHT/BLU WIRE
WHT/ORG WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component: -> Wiring diagram engine performance 3.5l (3 of 6) -> BREAKOUT TO FUEL INJECTOR 6)
