Ford Flex I (2008-2013) auto- lamp high sens pass beam Wiring diagram
This page shows the only wiring diagram for the component.auto- lamp high sens pass beam, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto- lamp high sens pass beam (1 of 1)
ASSEMBLY
AUTO OFF
AUTO- LAMP HIGH SENS PASS BEAM
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BRN WIRE
BRN WIRE
BRN/YEL WIRE
FLASH TO
FOG
FOG IND LOW PARK
FOG LAMP OFF PARK BEAM
FTP
FUSE 23
FUSE 8 FUSE 7
GRN WIRE
GRN/BRN WIRE
GRY WIRE
HEADLAMP SWITCH
HIGH BEAM RELAY
HOT AT ALL TIMES
LEFT HEADLAMP ASSEMBLY
LEFT LOW BEAM (FET)
LOW AUTO
MICRO -
MULTI- FUNCTION SWITCH
OFF
ORG/ WIRE
RIGHT HEADLAMP
RIGHT LOW BEAM (FET)
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
VIO WIRE
WHT WIRE
WHT/ORG WIRE
YEL WIRE
Go to component: -> Headlights circuit, without high intensity gas discharge headlights (1 of 2) -> AUTO- LAMP HIGH SENS PASS BEAM
