Ford Flex I (2008-2013) antenna pwr Wiring diagrams
This page contains all the electrical diagrams for the component. antenna pwr, in which he is found in the car Ford Flex I (2008-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
antenna pwr wiring diagram (1 of 3)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 VBATT
ANTENNA PWR
AUDIO CONTROL MODULE (ACM)
AUDIO INPUT JACK (W/O SYNC)
BLK/BLU WIRE
BLU WIRE
BLU/GRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COAX CABLE
COAX CABLE AM/FM ANT
COMPUTER DATA LINES SYSTEM
FUSE 28
FUSE 39
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN START
LEFT REAR SPEAKER
LF SPKR+ LR SPKR+ RR SPKR+ RF SPKR+ RF SPKR- GND
LF SPKR- LR SPKR- RR SPKR- SHIELD
MS CAN - MS CAN +
NCA WIRE
ORG/ WIRE
RIGHT "A" PILLAR SPEAKER
RIGHT FRONT SPEAKER (W/O SONY SOUND)
RIGHT REAR SPEAKER
SHIELD
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
VIO/ORG WIRE
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Base radio circuit (1 of 2) -> ANTENNA PWR
