Ford Flex I (2008-2013) 6 4 2 5 1 3 v power audio r in cvbs in audio lin wiring diagram
This page shows the only wiring diagram for the component.6 4 2 5 1 3 v power audio r in cvbs in audio lin, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
6 4 2 5 1 3 v power audio r in cvbs in audio lin wiring diagram (1 of 1)
2 3 4 1 CVBS OUT AUDIO R OUT AUDIO L OUT
3 2 4 AUDIO R OUT CVBS OUT AUDIO L OUT
3 4 2 5 1 GND AUDIO R IN CVBS IN AUDIO LIN
6 4 2 5 1 3 V POWER AUDIO R IN CVBS IN AUDIO LIN
BLK WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CLOCKSPRING (STEERING COLUMN ASSEMBLY)
GRN WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
LEFT DVD PLAYER (W/ REAR DVD)
MEDIA
NCA WIRE
PHONE
RED WIRE
RED/WHT WIRE
RIGHT DVD PLAYER (W/ REAR DVD)
RIGHT STEERING WHEEL SWITCH
SEEK
V POWER
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VOICE
VOL (-)
W/O SYNC
WHT WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Rear entertainment radio circuit (2 of 2) -> 6 4 2 5 1 3 V POWER AUDIO R IN CVBS IN AUDIO LIN
