Ford Flex I (2008-2013) 4 1 2 fan ctrl variable pwr gnd Wiring diagrams

This page contains all the electrical diagrams for the component. 4 1 2 fan ctrl variable pwr gnd, in which he is found in the car Ford Flex I (2008-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram 4 1 2 fan ctrl variable pwr gnd (1 of 2)

Wiring diagram 4 1 2 fan ctrl variable pwr gnd for Ford Flex I (2008-2013)

Get access

12 59 58 18 2 3 ACCR HS CAN + HS CAN - 39 49 41 58 CHT E-SIGRTN 4 1 2 FAN CTRL VARIABLE PWR GND A/C CLUTCH RELAY A/C COMPRESSOR CLUTCH FIELD COIL (LEFT FRONT AIR INLET MODE DOOR ACTUATOR (RIGHT SIDE OF DASH) AUTO LAMP SENSOR IN AUTOLAMP/SUNLOAD SENSOR (CENTER OF DASH) BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLOWER MOTOR (RIGHT SIDE BLOWER MOTOR RELAY BLOWER MOTOR SPEED CONTROLLER (RIGHT SIDE OF HVAC UNIT) BLU WIRE BLU/GRY WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM ELECTRONICS ENGINE COOLING FAN MOTOR (BEHIND RADIATOR) EXCEPT TURBO FAN CTRL VARIABLE FUSE 24 FUSE 28 FUSE 35 FUSE 45 BOX (SJB) (LEFT SIDE OF DASH) FUSE 46 GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT IN RUN OR ACC HOT W/ PCM POWER RELAY ENERGIZED MOTOR NCA WIRE OF ENGINE) OF HVAC UNIT) ORG/ WIRE POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE COMPT) PWM RED WIRE SMART JUNCTION SOLID STATE TURBO EXCEPT TURBO VIO WIRE VIO/GRN WIRE VIO/GRY WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/ORG WIRE

Go to component: -> Automatic a/c circuit (2 of 2) -> 4 1 2 FAN CTRL VARIABLE PWR GND

Wiring diagram 4 1 2 fan ctrl variable pwr gnd (2 of 2)

Wiring diagram 4 1 2 fan ctrl variable pwr gnd for Ford Flex I (2008-2013)

Get access

12 59 58 18 2 3 ACCR HS CAN + HS CAN - 39 49 41 58 CHT E-SIGRTN 4 1 2 FAN CTRL VARIABLE PWR GND A/C CLUTCH RELAY A/C COMPRESSOR CLUTCH FIELD COIL (LEFT FRONT AIR INLET MODE DOOR ACTUATOR (RIGHT SIDE OF DASH) BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLOWER MOTOR (BLOWER BLOWER MOTOR RELAY BLOWER MOTOR SPEED CONTROLLER (RIGHT SIDE OF HVAC UNIT) BLU WIRE BLU/GRY WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRONICS ENGINE COOLING FAN MOTOR (BEHIND RADIATOR) EXCEPT TURBO FAN CTRL VARIABLE FUSE 24 FUSE 28 FUSE 35 FUSE 45 FUSE 46 GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR ACC HOT W/ PCM POWER RELAY ENERGIZED MOTOR NCA WIRE OF ENGINE) OF HVAC UNIT) ORG/ WIRE POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE COMPT) PWM RED WIRE SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) TURBO EXCEPT TURBO VIO WIRE VIO/GRN WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE

Go to component: -> Manual a/c circuit (2 of 2) -> 4 1 2 FAN CTRL VARIABLE PWR GND
