Ford Flex I (2008-2013) 10 4 3 5 8 7 display rx video enable video+ display tx video- shield Wiring diagram

This page shows the only wiring diagram for the component.10 4 3 5 8 7 display rx video enable video+ display tx video- shield, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 10 4 3 5 8 7 display rx video enable video+ display tx video- shield (1 of 1)

Wiring diagram 10 4 3 5 8 7 display rx video enable video+ display tx video- shield for Ford Flex I (2008-2013)

Get access

1 2 3 4 5 6 7 8 9 10 11 12 BATT VIDEO SHIELD VIDEO+ RX DISPSG VIDEO+ GND 10 4 3 5 8 7 DISPLAY RX VIDEO ENABLE VIDEO+ DISPLAY TX VIDEO- SHIELD AUDIO CONTROL MODULE (ACM) BLK/BLU WIRE BLK/GRY WIRE BLU/ORG WIRE BRN/VIO WIRE CHOKE ELECTRONICS FRONT DISPLAY INTERFACE MODULE (FDIM) (CENTER OF DASH) FUSE 16 FUSE 35 GND PWR GRY WIRE GRY/BRN WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT IN START OR RUN NCA WIRE RED WIRE SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) VIDEO CAMERA (IF EQUIPPED) (CENTER OF LIFTGATE) VIDEO SHIELD VIDEO+ VIDEO- TX SHIELD VIDEO- VIO WIRE VIO/RED WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE YEL WIRE YEL/GRY WIRE

Go to component: -> Rear camera circuit -> 10 4 3 5 8 7 DISPLAY RX VIDEO ENABLE VIDEO+ DISPLAY TX VIDEO- SHIELD
