Ford Flex I (2008-2013) 1 4 2 pwr fan ctrl variable gnd Wiring diagram

This page shows the only wiring diagram for the component.1 4 2 pwr fan ctrl variable gnd, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 1 4 2 pwr fan ctrl variable gnd (1 of 1)

Wiring diagram 1 4 2 pwr fan ctrl variable gnd for Ford Flex I (2008-2013)

Get access

1 4 2 PWR FAN CTRL VARIABLE GND 2 3 59 58 HS CAN + HS CAN - BATTERY JUNCTION BLK/GRY WIRE BLU WIRE BLU/GRY WIRE CHT COMPUTER DATA LINES SYSTEM E-SIGRTN ELECTRONICS ENGINE COOLING FAN MOTOR (BEHIND RADIATOR) EXCEPT TURBO FAN CTRL VARIABLE FUSE 28 BOX (BJB) (LEFT SIDE OF ENGINE COMPT) GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES NCA WIRE POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE COMPT) TURBO WHT WIRE WHT/BLU WIRE

Go to component: -> Cooling fan circuit -> 1 4 2 PWR FAN CTRL VARIABLE GND
