Rear camera circuit for Ford Fiesta Mk6 facelift (2012-2019)

BLK/BLU WIRE BODY CONTROL MODULE BRN/VIO WIRE CENTRAL JUNCTION BOX CHOKE COMPUTER DATA LINES SYSTEM ELECTRONICS FUSE 10 FUSE 6 HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED HS CAN+ LIN NCA WIRE PWR GND REAR CAMERA VIDEO + REAR PARKING AID CAMERA (TOP CENTER OF LIFTGATE) RIGHT END OF DASH) SYNC MODULE (APIM) (LOWER RIGHT CENTER OF DASH) UN COMM VBATT VIO WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL/RED WIRE
