Wiring diagram engine performance 1.0l turbo for Ford Fiesta Mk6 facelift (2012-2019)

AIR CONDITIONING SYSTEM APP PWM BATTERY JUNCTION BOX (BJB) BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE CACCPC COOLING FANS SYSTEM ENABLE EVAPCP EVAPCV EVAPORATIVE EMISSION CANISTER VENT VALVE FPC FPDM FUEL PUMP RELAY FUEL TANK PRESSURE (FTP) SENSOR FUSE 11 FUSE 18 FUSE 20 FUSE 22 FUSE 24 FUSE 32 FUSE 33 FUSE 8 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/VIO WIRE GRY/ORG WIRE GRY/VIO WIRE HFC HOT AT ALL TIMES HTR(12) ACCR IAT ISP-R LFC LIN MAF MASS AIR FLOW/ TEMPERATURE (MAFT) SENSOR PCM POWER RELAY PCM WU POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (PCM) SIGRTN SMR STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM VACC VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/RED WIRE VREF W/ FPDM W/O FPDM WHT/BLU WIRE WHT/BRN WIRE WHT/ORG WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE

ACCELERATOR PEDAL POSITION (APP) SENSOR BLK WIRE BLK/BLU WIRE BLU WIRE BLU/GRY WIRE BODY CONTROL MODULE BRN WIRE BRN/WHT WIRE CENTRAL JUNCTION BOX (CJB) COMPUTER DATA LINES SYSTEM ENS FPC FPM FUEL LVL I/P FUEL LVL RTN FUEL PUMP DRIVE ASSEMBLY (TOP LEFT SIDE FUEL TANK) FUEL PUMP DRIVER MODULE (FPDM) FUSE 22 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/VIO WIRE GRY WIRE GRY/ORG WIRE HOT IN RUN OR START HS CAN+ INSTRUMENT PANEL CLUSTER (IPC) MS CAN + MTR NCA WIRE PCM WU RESTRAINTS CONTROL MODULE (RCM) RIGHT END OF DASH) VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VPWR W/ FPDM W/O FPDM WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/ORG WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE

ACPT AIR CONDITIONING (A/C) PRESSURE TRANSDUCER BLK/GRN WIRE BLU/GRY WIRE BPP BRN WIRE COMPUTER DATA LINES SYSTEM ENABLE FTP GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRY/ORG WIRE HS CAN+ IAT PCMRC POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE) PWRGND STARTING/ CHARGING SYSTEM TCBP TURBOCHARGER BOOST PRESSURE SENSOR VIO/GRN WIRE VIO/GRY WIRE VPWR WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/VIO WIRE

BLU/ORG WIRE BLU/WHT WIRE BRN/VIO WIRE BRN/YEL WIRE FUEL METERING VALVE FVRC- GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRY/BLU WIRE GRY/YEL WIRE LIN NCA WIRE POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE) SIGRTN STARTING/ CHARGING SYSTEM TACM+ VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE WHT/BRN WIRE WHT/ORG WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/VIO WIRE

BLU/ORG WIRE BLU/WHT WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE ELECTRONIC COMPRESSOR BYPASS VALVE ENGINE OIL PRESSURE (EOP) SWITCH EVAPORATIVE EMISSION CANISTER PURGE VALVE EXHAUST VARIABLE CAMSHAFT TIMING (VCT) OIL CONTROL SOLENOID FUEL INJECTOR 1 FUEL INJECTOR 2 FUEL INJECTOR 3 GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/YEL WIRE INTAKE VARIABLE CAMSHAFT TIMING (VCT) OIL CONTROL SOLENOID OIL PRESSURE CONTROL SOLENOID VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/WHT WIRE WASTEGATE CONTROL SOLENOID WHT/BRN WIRE WHT/ORG WIRE YEL/BLU WIRE YEL/VIO WIRE

BLK/YEL WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRN/GRN WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CKP CMP (11) CMP CRANKSHAFT POSITION (CKP) SENSOR ECBV ECT ENGINE COOLANT TEMPERATURE (ECT) SENSOR ETCREF ETCRTN EXHAUST CAMSHAFT POSITION (CMP) SENSOR FRP FUEL RAIL PRESSURE (FRP) SENSOR GRN WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/VIO WIRE GRY/YEL WIRE HTR(11) OPS IGNITION COIL ON PLUG 1 IGNITION COIL ON PLUG 2 IGNITION COIL ON PLUG 3 INTAKE CAMSHAFT POSITION (CMP) SENSOR MANIFOLD ABSOLUTE PRESSURE, TEMPERATURE (MAPT) SENSOR MAP OPS ORG/ WIRE POWERTRAIN CONTROL MODULE (PCM) SIGRTN TCWRVS TOP OF ENGINE) UREF(11) VCT(11) VCT(12) VIO WIRE VIO/WHT WIRE VREF WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/VIO WIRE
