Ford Fiesta Mk6 facelift (2012-2019) electronic compressor bypass valve Wiring diagrams
This page contains all the electrical diagrams for the component. electronic compressor bypass valve, in which he is found in the car Ford Fiesta Mk6 facelift (2012-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram electronic compressor bypass valve (1 of 2)
1.6L
1.6L 1.6L TURBO
A/C CLUTCH RELAY
ACCESSORY RELAY
AIR CONDITIONING (A/C) CLUTCH RELAY
BATTERY JUNCTION BOX (BJB)
BLU WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
CENTRAL JUNCTION BOX (BJB)
CENTRAL JUNCTION BOX (CJB)
COOLING FAN RELAY
DEGAS VALVE
ELECTRONIC COMPRESSOR BYPASS VALVE
EVAPORATIVE EMISSION CANISTER PURGE VALVE
EXHAUST GAS RECIRCULATION (EGR) COOLER BYPASS VALVE
EXHAUST VARIABLE CAMSHAFT TIMING (VCT) OIL CONTROL SOLENOID
FOG LAMP RELAY
FROM FUSE 18 (DIAGRAM 2 OF 6)
FROM FUSE 6 (DIAGRAM 1 OF 6)
FUEL PUMP RELAY
FUSE 11
FUSE 12
FUSE 17
FUSE 19
FUSE 21
FUSE 23
FUSE 24
FUSE 25
FUSE 31
FUSE 34
GRN WIRE
GRY WIRE
HIGH BEAM RELAY
HIGH FAN CONTROL (HFC) RELAY
INTAKE VARIABLE CAMSHAFT TIMING (VCT) OIL CONTROL SOLENOID
LOW FAN CONTROL (LFC) RELAY
MASTER WINDOW CONTROL SWITCH
OIL PRESSURE CONTROL SOLENOID
ORG/ WIRE
PASSENGER DOOR WINDOW CONTROL SWITCH
RED WIRE
RIGHT END OF DASH)
TURBOCHARGER BYPASS VALVE)
TURBOCHARGER WASTEGATE REGULATING VALVE SOLENOID (TCWRVS)
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WASTEGATE CONTROL SOLENOID
WHT WIRE
WHT/RED WIRE
Go to component -> Power distribution circuit (6 of 6) -> ELECTRONIC COMPRESSOR BYPASS VALVE
Wiring diagram electronic compressor bypass valve (2 of 2)
BLU/ORG WIRE
BLU/WHT WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
ELECTRONIC COMPRESSOR BYPASS VALVE
ENGINE OIL PRESSURE (EOP) SWITCH
EVAPORATIVE EMISSION CANISTER PURGE VALVE
EXHAUST VARIABLE CAMSHAFT TIMING (VCT) OIL CONTROL SOLENOID
FUEL INJECTOR 1
FUEL INJECTOR 2
FUEL INJECTOR 3
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/YEL WIRE
INTAKE VARIABLE CAMSHAFT TIMING (VCT) OIL CONTROL SOLENOID
OIL PRESSURE CONTROL SOLENOID
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/WHT WIRE
WASTEGATE CONTROL SOLENOID
WHT/BRN WIRE
WHT/ORG WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 1.0l turbo (5 of 6) -> ELECTRONIC COMPRESSOR BYPASS VALVE
