Power top/sunroof circuit for Ford Fiesta Mk6 (2008-2013)
Power top/sunroof circuit
BLK/BLU WIRE
BLU WIRE
BLU/RED WIRE
CENTRAL JUNCTION BOX (CJB) (RIGHT SIDE OF DASH)
CLOSE
CLOSE/DWN
FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
IGN
RED WIRE
ROOF OPENING PANEL MODULE (CENTER FRONT OF ROOF)
ROOF OPENING PANEL SWITCH
TILT DWN
TILT UP
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/WHT WIRE
VPWR
WHT/BLU WIRE
YEL/ORG WIRE
