Electronic power steering circuit for Ford Fiesta Mk6 (2008-2013)
Electronic power steering circuit
BLK/GRN WIRE
BLU/GRY WIRE
CENTRAL
COMPUTER DATA LINES SYSTEM
FUSE JUNCTION BOX (RIGHT SIDE OF DASH)
HOT AT ALL TIMES MEGA CURRENT FUSE BATTERY JUNCTION BOX (AT BATTERY)
HOT IN RUN OR START
HS CAN+
LOGIC PWR HS CAN -
MOTOR
POWER STEERING CONTROL MODULE (LEFT SIDE OF STEERING COLUMN)
PWR
PWR GND
STEERING ANGLE SENSOR
TORQUE SENSOR
WHT WIRE
WHT/BLU WIRE
YEL/RED WIRE
