Ford Fiesta Mk6 (2008-2013) power distribution system computer data lines system Wiring diagrams
This page contains all the electrical diagrams for the component. power distribution system computer data lines system, in which he is found in the car Ford Fiesta Mk6 (2008-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram power distribution system computer data lines system (1 of 2)
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BLU/ORG WIRE
BRAKE PEDAL SW SSB 1 SSB 2
BRN/VIO WIRE
BRN/YEL WIRE
CLUTCH 2 START/RUN OUT
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM STARTING/CHARGING SYSTEM
GRN/BLU WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HANDLE)
LEFT FRONT EXTERIOR DOOR
ORG/ WIRE
ORG/YEL WIRE
PARK DETECT SW
POWER DISTRIBUTION SYSTEM COMPUTER DATA LINES SYSTEM
RED WIRE
RELEASE SW
REMOTE FUNCTION ACTUATOR MODULE (UNDER FRONT PASSENGER'S SEAT)
REMOTE K-LINE GND VBATT FUNCTIONS IRX RECEIVER MODULE (CENTER FRONT OF ROOF)
RIGHT FRONT EXTERIOR DOOR HANDLE
RUN/ACC OUTPUT
SHIFT INTERLOCK SYSTEM
SMCS
STARTING/CHARGING SYSTEM POWER DISTRIBUTION SYSTEM
SW RIGHT SW LEFT IGN MONITOR MS CAN - MS CAN +
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/ORG WIRE
Go to component -> Forced entry circuit, with intelligent access (4 of 4) -> POWER DISTRIBUTION SYSTEM COMPUTER DATA LINES SYSTEM
Wiring diagram power distribution system computer data lines system (2 of 2)
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BLU/ORG WIRE
BRAKE PEDAL SW SSB 1 SSB 2
BRN/VIO WIRE
BRN/YEL WIRE
CLUTCH 2 START/RUN OUT
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM STARTING/CHARGING SYSTEM
GRN/BLU WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HANDLE)
LEFT FRONT EXTERIOR DOOR
ORG/ WIRE
ORG/YEL WIRE
PARK DETECT SW
POWER DISTRIBUTION SYSTEM COMPUTER DATA LINES SYSTEM
RED WIRE
RELEASE SW
REMOTE FUNCTION ACTUATOR MODULE (UNDER FRONT PASSENGER'S SEAT)
REMOTE K-LINE GND VBATT FUNCTIONS IRX RECEIVER MODULE (CENTER FRONT OF ROOF)
RIGHT FRONT EXTERIOR DOOR HANDLE
RUN/ACC OUTPUT
SHIFT INTERLOCK SYSTEM
SMCS
STARTING/CHARGING SYSTEM POWER DISTRIBUTION SYSTEM
SW RIGHT SW LEFT IGN MONITOR MS CAN - MS CAN +
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/ORG WIRE
Go to component -> Power door locks circuit, with intelligent access (4 of 4) -> POWER DISTRIBUTION SYSTEM COMPUTER DATA LINES SYSTEM
