Ford Fiesta ST VII (2018-2021) w/ map lamps w/o map lamps Wiring diagram
This page shows the only wiring diagram for the component.w/ map lamps w/o map lamps, which is found in the car Ford Fiesta ST VII (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ map lamps w/o map lamps (1 of 1)
4 DOOR
5 DOOR
AUTO DIMMING INTERIOR MIRROR
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
DRIVER DOOR LATCH
DRIVER SIDE EXTERIOR MIRROR
EXTERIOR MIRROR SWITCH
FRONT INTERIOR LAMP
FUEL PUMP DRIVE ASSEMBLY
FUEL PUMP DRIVER MODULE (FPDM)
GLOBAL POSITIONING SYSTEM MODULE (GPSM)
HIGH MOUNTED STOP LAMP
HIGH MOUNTED STOPLAMP
INTRUSION SENSOR
LEFT FRONT EXTERIOR DOOR HANDLE
LEFT FRONT SEAT CUSHION HEATER
LEFT REAR DOOR LATCH
LEFT REAR DOOR WINDOW CONTROL SWITCH
LEFT REAR LAMP ASSEMBLY
LEFT REVERSING LAMP ASSEMBLY
LIFTGATE/ LUGGAGE COMPARTMENT LID RELEASE ACTUATOR
LIFTGATE/LUGGAGE COMPARTMENT LID RELEASE SWITCH
MASTER WINDOW CONTROL SWITCH
NCA WIRE
POWER WINDOW MODULE
RADIO FREQUENCY (RF) RECEIVER
RAIN SENSOR MODULE
REAR INTERIOR LAMP
REAR WINDOW HEATED ELEMENT
REAR WINDOW WIPER MOTOR
RIGHT REVERSING LAMP ASSEMBLY
W/ ANTI- THEFT
W/ KEYLESS ENTRY
W/ LED
W/ MAP LAMPS W/O MAP LAMPS
W/ OVERHEAD CONSOLE
W/ ROOF OPENING PANEL
W/O LED
W/O OVERHEAD CONSOLE
W/O RAIN SENSOR W/ RAIN SENSOR
Go to component -> Ground distribution circuit (4 of 4) -> W/ MAP LAMPS W/O MAP LAMPS
