Ford Fiesta ST VII (2018-2021) tilt dwn wiring diagram
This page shows the only wiring diagram for the component.tilt dwn, which is found in the car Ford Fiesta ST VII (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
tilt dwn wiring diagram (1 of 1)
BLK/BLU WIRE
BLU WIRE
BLU/RED WIRE
CENTRAL JUNCTION BOX (CJB)
CLOSE
CLOSE/DWN
FUSE 35
FUSE 8
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
IGN
OVERHEAD CONSOLE SWITCH ASSEMBLY
RED WIRE
RIGHT END OF DASH)
ROOF OPENING PANEL MODULE
TILT DWN
TILT UP
VIO/BRN WIRE
VIO/WHT WIRE
VPWR
WHT/BLU WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Power top/sunroof circuit -> TILT DWN
