Ford Fiesta ST VII (2018-2021) right instrument panel lamp Wiring diagram
This page shows the only wiring diagram for the component.right instrument panel lamp, which is found in the car Ford Fiesta ST VII (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right instrument panel lamp (1 of 1)
AMBIENT LIGHTING MODULE (UNDER CENTER CONSOLE)
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLUE
BRN WIRE
BRN/YEL WIRE
GREEN
GRN WIRE
GRN/RED WIRE
LED RTN
LEFT CUPHOLDER LAMP
LEFT FRONT FOOTWELL LAMP
LEFT REAR FOOTWELL LAMP
ORG/ WIRE
PASSENGER HEATED SEAT/AMBIENT LIGHTING SWITCH
RED WIRE
RIGHT CUPHOLDER LAMP
RIGHT FRONT FOOTWELL LAMP
RIGHT INSTRUMENT PANEL LAMP
RIGHT REAR FOOTWELL LAMP
SW INPUT
VIO/BRN WIRE
VPWR
WHT/BRN WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> RIGHT INSTRUMENT PANEL LAMP
