Ford Fiesta ST VII (2018-2021) liftgate/ decklid release switch Wiring diagram
This page shows the only wiring diagram for the component.liftgate/ decklid release switch, which is found in the car Ford Fiesta ST VII (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram liftgate/ decklid release switch (1 of 1)
5 DOOR
ANT
BATTERY JUNCTION BOX (BJB)
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN/RED WIRE
CENTRAL JUNCTION BOX (CJB)
COMPUTER DATA LINES SYSTEM
FUSE 14
FUSE 26
FUSE 4
FUSE 7
FUSE 9
GND PWR
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HS CAN+
INSTRUMENT PANEL CLUSTER (IPC)
K LINE
K-LINE IRX
KEYLESS ENTRY REAR ANTENNA
LICENSE LAMPS
LIFTGATE/ DECKLID RELEASE SWITCH
LIFTGATE/ LUGGAGE COMPARTMENT LID RELEASE SWITCH
LIFTGATE/LUGGAGE COMPARTMENT LID RELEASE ACTUATOR
LOGIC
MS CAN +
PWR GND
RADIO FREQUENCY (RF) RECEIVER
RED WIRE
REMOTE FUNCTION ACTUATOR (RFA) MODULE
RIGHT END OF DASH)
SIG GND 1
SIG GND 2
TAILGATE RELEASE SW
TRUNK AJAR
TRUNK MOTOR
TRUNK REL SW
VBATT
VBATT LOCKING
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
W/ KEYLESS ENTRY
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL/ORG WIRE
Go to component -> Trunk release circuit -> LIFTGATE/ DECKLID RELEASE SWITCH
