Ford Fiesta ST VII (2018-2021) left reversing lamp assembly Wiring diagrams
This page contains all the electrical diagrams for the component. left reversing lamp assembly, in which he is found in the car Ford Fiesta ST VII (2018-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left reversing lamp assembly (1 of 3)
1.6L
4 DOOR
5 DOOR
A/T
AUTO- DIMMING INTERIOR MIRROR UNIT
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
CENTRAL JUNCTION BOX (CJB)
COMPUTER DATA LINES SYSTEM
FUSE 6
GLOBAL POSITIONING SYSTEM MODULE
HOT IN START OR RUN
HS CAN+
LEFT REAR LAMP ASSEMBLY
LEFT REVERSING LAMP ASSEMBLY
M/T
M/T A/T
REVERSE
REVERSING LAMP RELAY
REVERSING LAMP SWITCH
RIGHT END OF DASH)
RIGHT REAR LAMP ASSEMBLY
RIGHT REVERSING LAMP ASSEMBLY
RLRC
TRANSMISSION CONTROL MODULE (TCM)
VIO WIRE
W/ RAIN SENSOR W/O RAIN SENSOR
WHT WIRE
WHT/BLU WIRE
Go to component -> Backup lamps circuit -> LEFT REVERSING LAMP ASSEMBLY
Wiring diagram left reversing lamp assembly (2 of 3)
4 DOOR
5 DOOR
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN/YEL WIRE
CENTRAL JUNCTION BOX (CJB)
FUSE 18
FUSE 21
GRN/ORG WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
LEFT EXTERIOR MIRROR
LEFT HEADLAMP ASSEMBLY
LEFT REVERSING LAMP ASSEMBLY
LICENSE LAMPS
LIFTGATE/LUGGAGE COMPARTMENT LID RELEASE SWITCH
NCA WIRE
PARK
RIGHT END OF DASH)
RIGHT EXTERIOR MIRROR
RIGHT HEADLAMP ASSEMBLY
RIGHT REVERSING LAMP ASSEMBLY
TURN
VIO/GRN WIRE
W/O LED LIGHTING
WHT/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Exterior lamps circuit (2 of 3) -> LEFT REVERSING LAMP ASSEMBLY
Wiring diagram left reversing lamp assembly (3 of 3)
4 DOOR
5 DOOR
AUTO DIMMING INTERIOR MIRROR
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
DRIVER DOOR LATCH
DRIVER SIDE EXTERIOR MIRROR
EXTERIOR MIRROR SWITCH
FRONT INTERIOR LAMP
FUEL PUMP DRIVE ASSEMBLY
FUEL PUMP DRIVER MODULE (FPDM)
GLOBAL POSITIONING SYSTEM MODULE (GPSM)
HIGH MOUNTED STOP LAMP
HIGH MOUNTED STOPLAMP
INTRUSION SENSOR
LEFT FRONT EXTERIOR DOOR HANDLE
LEFT FRONT SEAT CUSHION HEATER
LEFT REAR DOOR LATCH
LEFT REAR DOOR WINDOW CONTROL SWITCH
LEFT REAR LAMP ASSEMBLY
LEFT REVERSING LAMP ASSEMBLY
LIFTGATE/ LUGGAGE COMPARTMENT LID RELEASE ACTUATOR
LIFTGATE/LUGGAGE COMPARTMENT LID RELEASE SWITCH
MASTER WINDOW CONTROL SWITCH
NCA WIRE
POWER WINDOW MODULE
RADIO FREQUENCY (RF) RECEIVER
RAIN SENSOR MODULE
REAR INTERIOR LAMP
REAR WINDOW HEATED ELEMENT
REAR WINDOW WIPER MOTOR
RIGHT REVERSING LAMP ASSEMBLY
W/ ANTI- THEFT
W/ KEYLESS ENTRY
W/ LED
W/ MAP LAMPS W/O MAP LAMPS
W/ OVERHEAD CONSOLE
W/ ROOF OPENING PANEL
W/O LED
W/O OVERHEAD CONSOLE
W/O RAIN SENSOR W/ RAIN SENSOR
Go to component -> Ground distribution circuit (4 of 4) -> LEFT REVERSING LAMP ASSEMBLY
