Ford Fiesta ST VII (2018-2021) clutch pedal position bottom of travel switch Wiring diagram
This page shows the only wiring diagram for the component.clutch pedal position bottom of travel switch, which is found in the car Ford Fiesta ST VII (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram clutch pedal position bottom of travel switch (1 of 1)
ACCELERATOR PEDAL POSITION SENSOR
BLK/GRN WIRE
BLK/GRY WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BRK PEDAL SW
CLOCK- SPRING
CLUTCH PEDAL CRUISE CONTROL DEACTIVATOR SWITCH
CLUTCH PEDAL POSITION BOTTOM OF TRAVEL SWITCH
CLUTCH PEDAL SW
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL DEACTIVATOR SWITCH
CTRL + RES
CTRL RTN
GRN/BRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
HS CAN+
INSTRUMENT PANEL CLUSTER (IPC)
M/T
OFF
P/N SW/ CLUTCH 2
REMOTE FUNCTION ACTUATOR MODULE
RESUME
RIGHT STEERING WHEEL SWITCH
SET-
VIO/GRY WIRE
VPWR
W/ INTELLIGENT ACCESS
W/ PUSH BUTTON START W/O PUSH BUTTON START
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Cruise control circuit (2 of 2) -> CLUTCH PEDAL POSITION BOTTOM OF TRAVEL SWITCH
