Computer data lines circuit, early production for Ford F-350 XIV (2017-2020)

6.2L FLEX FUEL, 6.8L 6.7L TURBO DIESEL BLK/GRY WIRE BLK/VIO WIRE BODY CONTROL MODULE (BCM) DATA LINK CONNECTOR (DLC) FUSE 13 FUSE 15 GATEWAY MODULE (LEFT SIDE OF DASH) GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/RED WIRE GRY/VIO WIRE HOT AT ALL TIMES MICRO - POWERTRAIN CONTROL MODULE (PCM) SPLICE BLOCK 3 (LEFT SIDE OF ENGINE COMPT) TRAILER CAMERA/ TRAILER TPMS CONNECTOR TRAILER TIRE PRESSURE MONITOR SYSTEM (TPMS) MODULE TRANSMISSION CONTROL MODULE (TCM) VIO/GRN WIRE VIO/ORG WIRE W/ CREW CHIEF WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE

DRIVER DOOR MODULE (DDM) DRIVER MULTI-CONTOUR SEAT MODULE DRIVER SEAT MODULE (DSM) GLOBAL POSITIONING SYSTEM MODULE (GPSM) GRN/BLU WIRE GRN/ORG WIRE GRY/BLU WIRE GRY/ORG WIRE HEATED STEERING WHEEL MODULE (HSWM) SPLICE BLOCK 1 (LEFT KICK PANEL) TELEMATICS MODULE TRAILER TOW MODULE VIO/ORG WIRE W/ CREW CHIEF WHT WIRE WHT/BLU WIRE WHT/GRN WIRE

AUXILIARY LAMP MODULE DRIVER MULTI-CONTOUR SEAT MODULE DRIVER SEAT MODULE (DSM) FRONT CONTROLS INTERFACE MODULE (FCIM) FRONT SEAT CLIMATE CONTROL MODULE (SCME) GRN/BLU WIRE GRN/ORG WIRE GRY/BLU WIRE GRY/ORG WIRE PASSENGER DOOR MODULE (PDM) PASSENGER MULTI- CONTOUR SEAT MODULE POWER RUNNING BOARD (PRB) MODULE RADIO TRANSCEIVER MODULE (RTM) TEST CONNECTOR VIO/ORG WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE

GRN/BLU WIRE GRN/ORG WIRE GRY/BLU WIRE GRY/ORG WIRE LEFT REAR LAMP ASSEMBLY LEFT REVERSING LAMP RIGHT REAR LAMP ASSEMBLY RIGHT REVERSING LAMP SPLICE BLOCK 7 (REAR OF BED) VIO/ORG WIRE W/ LED W/ NARROW FRAME W/O BLIS WHT WIRE WHT/BLU WIRE WHT/GRN WIRE

AUDIO CONTROL MODULE (ACM) AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE) BATTERY ENERGY CONTROL MODULE B (BECMB) CLOCKSPRING/ STEERING ANGLE SENSOR MODULE (SASM) FRONT CONTROL/ DISPLAY INTERFACE MODULE (FCDIM) GRN/BLU WIRE GRN/ORG WIRE GRY/BLU WIRE INSTRUMENT PANEL CLUSTER (IPC) NCA WIRE STEERING EFFORT CONTROL MODULE (SECM) SYNC MODULE (APIM) TEST CONNECTOR W/ 4 INCH DISPLAY W/ ACTIVE STEERING W/ POWER SEATS W/ SONY W/O SONY WHT WIRE WHT/BLU WIRE WHT/GRN WIRE

ANTI-LOCK BRAKE SYSTEM (ABS) MODULE AUTO DIMMING INTERIOR MIRROR CRUISE CONTROL MODULE (C-CM) GRN/ORG WIRE GRY/BLU WIRE HEAD-UP DISPLAY (HUD) MODULE IMAGE PROCESSING MODULE B (IPMB) RESTRAINTS CONTROL MODULE (RCM) RIGHT END OF DASH) SPLICE BLOCK 4 (LEFT CENTER OF DASH) STEERING COLUMN CONTROL MODULE (SCCM) TRAILER BRAKE CONTROL (TBC) MODULE TRANSFER CASE CONTROL MODULE (TCCM) W/ TRAILER CAMERA W/ 360 CAMERA
