Ford F-350 XIV (2017-2020) w/ intrusion sensor w/o intrusion sensor 2 Wiring diagram
This page shows the only wiring diagram for the component.w/ intrusion sensor w/o intrusion sensor 2, which is found in the car Ford F-350 XIV (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ intrusion sensor w/o intrusion sensor 2 (1 of 1)
AUTO DIMMING INTERIOR MIRROR
BATTERY JUNCTION BOX (BJB)
BLK/YEL WIRE
BLU/BRN WIRE
BODY CONTROL MODULE (BCM)
FUSE 36
FUSE 48
GRN/BLU WIRE
GRN/BRN WIRE
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
MICRO -
NAVIGATION SYSTEM
NCA WIRE
POWER DISTRIBUTION SYSTEM
REAR VIDEO -
REV INHIBIT
REV LPS (FET)
RUN/START
SUPER CAB, CREW CAB
VIO/GRY WIRE
VIO/RED WIRE
W/ CAMERA
W/ INTRUSION SENSOR W/O INTRUSION SENSOR 2
Go to component -> Electrochromic mirror circuit, w/o lane departure warning -> W/ INTRUSION SENSOR W/O INTRUSION SENSOR 2
