Ford F-350 XIV (2017-2020) low washer fluid warning indicator switch Wiring diagram
This page shows the only wiring diagram for the component.low washer fluid warning indicator switch, which is found in the car Ford F-350 XIV (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low washer fluid warning indicator switch (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/WHT WIRE
CAN (+)
COMPUTER DATA LINES SYSTEM
FRT WIPER HI
FUNCTION SWITCH
FUSE 13
FUSE 77
FUSE 96
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
HI INPUT
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC GND
LOW WASHER
LOW WASHER FLUID WARNING INDICATOR SWITCH
MICRO -
MULTI-
RAIN SENSOR MODULE (CENTER OF WINDSHIELD)
RED WIRE
RUN/ ACC (FET)
STEERING COLUMN CONTROL MODULE (SCCM)
SUPER CAB/CREW CAB REGULAR CAB
SUPER CAB/CREW CAB, REGULAR CAB W/ MULTI- FUNCTION DISPLAY
VBATT
VIO WIRE
VPWR
WASH
WHT WIRE
WHT/GRN WIRE
WINDSHIELD WASHER PUMP MOTOR
WINDSHIELD WIPER MOTOR
WIPER RELAY
YEL WIRE
YEL/GRY WIRE
Go to component -> Wiper/washer circuit -> LOW WASHER FLUID WARNING INDICATOR SWITCH
