Ford F-350 XIV (2017-2020) intake throttle actuator Wiring diagram
This page shows the only wiring diagram for the component.intake throttle actuator, which is found in the car Ford F-350 XIV (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram intake throttle actuator (1 of 1)
BLU/BRN WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/YEL WIRE
CRANKSHAFT POSITION (CKP) SENSOR
EGR TEMPERATURE BANK 1 SENSOR 1 (EGRT 11)
EGR TEMPERATURE BANK 1 SENSOR 2 (EGRT 12)
ENGINE COOLANT TEMPERATURE (ECT) SENSOR
EXHAUST GAS RECIRCULATION (EGR) VALVE
FUEL INJECTOR 2
FUEL INJECTOR 3
FUEL INJECTOR 5
FUEL INJECTOR 8
FUEL PRESSURE, TEMPERATURE SENSOR
FUEL RAIL PRESSURE (FRP) SENSOR
GRN WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/VIO WIRE
GRY/YEL WIRE
INTAKE THROTTLE ACTUATOR
THROTTLE BODY ASSEMBLY
VIO/GRY WIRE
VIO/ORG WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 6.7l turbo diesel (7 of 8) -> INTAKE THROTTLE ACTUATOR
