Instrument illumination circuit for Ford F-250 XIV (2017-2024)

ADJUSTABLE PEDAL SWITCH AUTOLAMP AUTOLAMP ON BACK LTG (FET) BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/YEL WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM DIM + DOME LAMP (W/O OVERHEAD CONSOLE) FUSE 13 FUSE 2 GRN/ORG WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE H/L ON HAZARD/HILL DESCENT SWITCH HEAD/PARK HEADLAMP SWITCH HOT AT ALL TIMES LAMPS OFF LANE KEEPING SYSTEM/ CAMERA SELECTION SWITCH LOGIC GND LOW BEAM REQ MICRO - MODE SELECT SWITCH (MSS) MULTI- FUNCTION SWITCH OFF OVERHEAD CONSOLE PARK PARK LAMPS ON POWER DISTRIBUTION SYSTEM PRO TRAILER BACKUP ASSIST CONTROL KNOB PUSH BUTTON START IGNITION SWITCH REAR HEATED SEAT SWITCH SPOT LAMP SWITCH STABILITY ASSIST/ ENGINE BRAKE SWITCH STEERING COLUMN CONTROL MODULE (SCCM) SUPER CAB, CREW CAB TAILGATE RELEASE SWITCH UPFITTER SWITCH (IF EQUIPPED) VBATT VIO/GRN WIRE VIO/GRY WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/RED WIRE YEL/VIO WIRE

BLK WIRE BLK/GRY (OR BLK/GRN) WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/GRN WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) CLOCKSPRING COMPUTER DATA LINES SYSTEM DRIVER DOOR MODULE (DDM) FUSE 23 FUSE 26 GRN/BRN WIRE GRY/ORG WIRE HOT AT ALL TIMES ILLUM LED LEFT FRONT DOOR LOCK SWITCH LEFT STEERING WHEEL SWITCH MASTER WINDOW CONTROL SWITCH NCA WIRE PASSENGER DOOR MODULE (PDM) PASSENGER DOOR WINDOW CONTROL SWITCH REGULAR CAB SUPER CAB, CREW CAB W/ ADAPTIVE STEERING W/O ADAPTIVE STEERING RIGHT FRONT DOOR LOCK SWITCH RIGHT STEERING WHEEL SWITCH RTN TELESCOPING EXTERIOR REAR VIEW MIRROR SWITCH VBATT VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE W/ CRUISE CONTROL W/O CRUISE CONTROL W/ MEMORY W/O MEMORY WHT/RED WIRE YEL/RED WIRE
