Ford F-250 XIV (2017-2024) w/ power seats, power running boards Wiring diagram
This page shows the only wiring diagram for the component.w/ power seats, power running boards, which is found in the car Ford F-250 XIV (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ power seats, power running boards (1 of 1)
BLU WIRE
BLU/GRN WIRE
DRIVER MULTI-CONTOUR SEAT MODULE
DRIVER SEAT MODULE (DSM)
FRONT CONTROLS INTERFACE MODULE (FCIM)
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
LEFT REAR LAMP ASSEMBLY
PARKING AID MODULE (PAM)
PASSENGER DOOR MODULE (PDM)
PASSENGER MULTI- CONTOUR SEAT MODULE
POWER RUNNING BOARD (PRB) MODULE
RADIO TRANSCEIVER MODULE (RTM)
RIGHT REAR LAMP ASSEMBLY
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/ LED
W/ MULTI-CONTOUR SEAT
W/ POWER RUNNING BOARD
W/ POWER SEATS, POWER RUNNING BOARDS
W/O BLIS
W/O LED
W/O POWER SEATS, POWER RUNNING BOARDS NARROW FRAME WIDE FRAME
WHT WIRE
WHT/GRN WIRE
Go to component -> Computer data lines circuit (2 of 4) -> W/ POWER SEATS, POWER RUNNING BOARDS
