Ford F-250 XIV (2017-2024) vpwr/trailer batt charge vpwr Wiring diagram
This page shows the only wiring diagram for the component.vpwr/trailer batt charge vpwr, which is found in the car Ford F-250 XIV (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vpwr/trailer batt charge vpwr (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BPP
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
CHARGING
COMPUTER DATA LINES SYSTEM
FUSE 44
FUSE 56
FUSE 60
FUSE 62
FUSE 63
FUSE 7
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
ILLUM
LT STOP/TURN
ORG/ WIRE
PARK
PRO TRAILER BACKUP ASSIST CONTROL KNOB
RT STOP/TURN
SIG
TBA
TBA SIG
TRAILER BRAKE CONTROL MODULE (TBM)
TRAILER BRAKES
TRAILER TOW BACKUP LAMP RELAY
TRAILER TOW BATTERY CHARGE RELAY
TRAILER TOW MODULE
TRAILER TOW PARK LAMP RELAY
VBATT
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
VPWR/TRAILER BATT CHARGE VPWR
W/ TRAILER BRAKE CONTROL MODULE
W/ TRAILER TOW MODULE
W/O TRAILER BRAKE CONTROL MODULE
W/O TRAILER TOW MODULE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Trailer/camper adapter circuit (1 of 3) -> VPWR/TRAILER BATT CHARGE VPWR
