Ford F-250 XIV (2017-2024) vio/org Wiring diagrams
This page contains all the electrical diagrams for the component. vio/org, in which he is found in the car Ford F-250 XIV (2017-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
vio/org wiring diagram (51 of 85)
BATTERY JUNCTION BOX (BJB)
BLIS GND
BLIS IND
BLIS VPWR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM)
FUSE 23
FUSE 26
FUSE 51
GRN/WHT WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
LEFT EXTERIOR MIRROR
LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
LEFT REAR LAMP ASSEMBLY
MIRR SENS/ BLIS GND
PASSENGER DOOR MODULE (PDM)
RIGHT EXTERIOR MIRROR
RIGHT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
RIGHT REAR LAMP ASSEMBLY
VBATT
VIO/ORG WIRE
W/ REAR LED LAMPS W/O REAR LED LAMPS
WHT/RED WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Blind spot information system circuit -> VIO/ORG WIRE
vio/org wiring diagram (52 of 85)
6.7L TURBO DIESEL
7.3L
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BLK/VIO WIRE
BLU WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (BCM)
BRN/RED WIRE
BRN/YEL WIRE
CHAS GND
DATA LINK CONNECTOR (DLC)
DRIVER DOOR MODULE (DDM)
FUSE 12
FUSE 70
GATEWAY MODULE (BELOW LEFT SIDE OF DASH)
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HEATED STEERING WHEEL MODULE (HSWM)
HOT AT ALL TIMES
MICRO -
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM)
SIG GND
TRAILER TOW MODULE
TRANSMISSION CONTROL MODULE (TCM)
VBATT
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/ HEATED STEERING WHEEL
W/O HEATED STEERING WHEEL
W/O TRAILER TOW
WHT WIRE
WHT/GRN WIRE
Go to component -> Computer data lines circuit (1 of 4) -> VIO/ORG WIRE
vio/org wiring diagram (53 of 85)
BLU WIRE
BLU/GRN WIRE
DRIVER MULTI-CONTOUR SEAT MODULE
DRIVER SEAT MODULE (DSM)
FRONT CONTROLS INTERFACE MODULE (FCIM)
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
LEFT REAR LAMP ASSEMBLY
PARKING AID MODULE (PAM)
PASSENGER DOOR MODULE (PDM)
PASSENGER MULTI- CONTOUR SEAT MODULE
POWER RUNNING BOARD (PRB) MODULE
RADIO TRANSCEIVER MODULE (RTM)
RIGHT REAR LAMP ASSEMBLY
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/ LED
W/ MULTI-CONTOUR SEAT
W/ POWER RUNNING BOARD
W/ POWER SEATS, POWER RUNNING BOARDS
W/O BLIS
W/O LED
W/O POWER SEATS, POWER RUNNING BOARDS NARROW FRAME WIDE FRAME
WHT WIRE
WHT/GRN WIRE
Go to component -> Computer data lines circuit (2 of 4) -> VIO/ORG WIRE
vio/org wiring diagram (54 of 85)
6.2L FLEX FUEL, 7.3L
6.7L TURBO DIESEL
AFC
AUX COOLING FAN MOTOR
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
CHT
COMPUTER DATA LINES SYSTEM
COOLING FAN (6.2L FLEX FUEL, 7.3L)
COOLING FAN (6.7L TURBO DIESEL)
CYLINDER HEAD TEMPERATURE (CHT) SENSOR
ECBV TH
ECT
ENGINE COOLANT TEMPERATURE (ECT) SENSOR
FCV
FSS
FUSE 15
FUSE 17
FUSE 75
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL MODULE (PCM)
PWR GND
RED WIRE
SIGRTN
SIGRTN FCV
TRANSMISSION FLUID HEATER COOLANT CONTROL VALVE
VBPWR
VBPWR VPWR FSS
VIO WIRE
VIO/ORG WIRE
VIO/RED WIRE
VPWR
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Cooling fan circuit -> VIO/ORG WIRE
vio/org wiring diagram (55 of 85)
6.2L FLEX FUEL, 7.3L
6.7L TURBO DIESEL
ACCELERATOR PEDAL POSITION (APP) SENSOR
BATTERY JUNCTION BOX (BJB)
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BPS 35 21 BPP
BRAKE PEDAL POSITION (BPP) SWITCH
BRN/BLU WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL MODULE (CCM)
ELECTRONIC THROTTLE CONTROL (ETC)
FUSE 50
FUSE 53
GRN/BRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
HOT W/ RUN/START RELAY ENERGIZED
IMAGE PROCESSING MODULE A (IPMA)
INTAKE THROTTLE ACTUATOR (6.7L TURBO DIESEL)
ISP-R
LOGIC GND
OSS +
POWERTRAIN CONTROL MODULE (PCM)
PWR GND
TACM+
TP RTN ETC RTN
TPREF ETC REF
TR GND
TRGND
TRP
TRS TR-P
TSS
VBATT
VBPWR
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Cruise control circuit (1 of 2) -> VIO/ORG WIRE
vio/org wiring diagram (56 of 85)
AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE)
AUDIO ENABLE IN
BLK/VIO WIRE
BLU WIRE
BODY CONTROL MODULE (BCM)
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
CREW CAB, SUPER CAB
CTR SPKR+
FUSE 13
FUSE 15
FUSE 17
FUSE 28
FUSE 32
FUSE 8
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
INSTRUMENT PANEL CENTER SPEAKER
L/R SUBWOOFER (-)
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
LF SPKR
LR SPKR
POWER DISTRIBUTION SYSTEM
RF SPKR
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
RR SPKR
RR SUBWOOFER -
SUPER CAB, CREW CAB
VBATT
VIO/ORG WIRE
VIO/RED WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Navigation circuit (1 of 5) -> VIO/ORG WIRE
vio/org wiring diagram (57 of 85)
BATTERY JUNCTION BOX (BJB)
BLK/WHT WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FUSE 6
GRN/BLU WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HALL EFFECT PWR
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LEFT RUNNING BOARD MOTOR
LH RB DEPLOY
LH RB HALL EFFECT SIG
LH RB STOW
POWER RUNNING BOARD (PRB) MODULE
RH RB DEPLOY
RH RB HALL EFFECT SIG
RH RB STOW
RIGHT RUNNING BOARD MOTOR
SSR RTN
VBATT
VIO/GRY WIRE
VIO/ORG WIRE
WHT WIRE
WHT/GRN WIRE
Go to component -> Retractable running boards circuit -> VIO/ORG WIRE
vio/org wiring diagram (58 of 85)
10 SPEED A/T
6 SPEED A/T
6.7L TURBO DIESEL
7.3L, 6.2L FLEX FUEL
BATTERY JUNCTION BOX (BJB)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BPP
BRAKE PEDAL POSITION (BPP) SWITCH
BRAKE SHIFT INTERLOCK ACTUATOR
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BSI (FET)
CASE GND
COMPUTER DATA LINES SYSTEM
FUSE 20
FUSE 50
FUSE 7
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
IGNITION SWITCH
IN PARK
INSTRUMENT PANEL CLUSTER (IPC)
ISP-R
KEY IN
LOCK
MICRO -
OSS +
PARK DETECT
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPT)
PWR GND
S120 (6.7L TURBO DEISEL)
TR GND
TRANSMISSION ASSEMBLY
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION RANGE (TR) SENSOR
TRANSMISSIONS SYSTEM
TRGND
TRP
TRS/TR-P
TSS
VBPWR
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/ MANUAL COLUMN
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Shift interlock circuit -> VIO/ORG WIRE
vio/org wiring diagram (59 of 85)
BATTERY JUNCTION BOX (BJB)
BLK/YEL WIRE
BLU WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 31
FUSE 51
GRN/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
K LINE
MICRO -
RADIO TRANSCEIVER MODULE (RTM) (TOP RIGHT REAR OF ROOF)
TRAILER CAMERA/ TRAILER TPMS CONNECTOR
TRAILER TIRE PRESSURE MONITOR SYSTEM (TPMS) MODULE
VBATT
VIO/GRN WIRE
VIO/ORG WIRE
VPWR
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Tire pressure monitoring circuit -> VIO/ORG WIRE
vio/org wiring diagram (60 of 85)
10 SPEED A/T
6 SPEED A/T
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COOLING FANS SYSTEM
CPC
FMSS
FSS
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/YEL WIRE
ISS B
LPC
OSS +
POWERTRAIN CONTROL MODULE (PCM)
SIG RTN
SIGRTN
SSA
SSB
SSC
SSD
SSE
SSF
TFT
TFT OUT/
TR GND
TR-P
TRS
TSPC
TSS
VBPWR
VIO/GRN WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 6.2l flex fuel (12 of 12) -> VIO/ORG WIRE
