Ford F-250 XIV (2017-2024) trailer tow lh stop/ turn relay Wiring diagrams
This page contains all the electrical diagrams for the component. trailer tow lh stop/ turn relay, in which he is found in the car Ford F-250 XIV (2017-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram trailer tow lh stop/ turn relay (1 of 2)
6.7L TURBO DIESEL
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BATTERY JUNCTION BOX (BJB) (RIGHT SIDE OF ENGINE COMPT)
BLOWER RELAY
BLU/RED WIRE
BODY CONTROL MODULE (BCM) (RIGHT KICK PANEL)
BRN WIRE
BRN/GRN WIRE
CLOCKSPRING/ STEERING ANGLE SENSOR MODULE (SASM)
CRUISE CONTROL MODULE (CCM)
FROM FUSE 45 (DIAGRAM 1 OF 9)
FROM REAR WINDOW DEFROST RELAY (DIAGRAM 2 OF 9)
FUEL PUMP (FP) RELAY
FUSE 13
FUSE 14
FUSE 16
FUSE 17
FUSE 18
FUSE 19
FUSE 25
FUSE 32
FUSE 39
FUSE 44
FUSE 47
FUSE 5
FUSE 6
FUSE 60
FUSE 69
FUSE 7
FUSE 70
FUSE 8
FUSE 9
GLOW PLUG CONTROL MODULE (GPCM)
GRN/ORG WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
GRY/RED WIRE
HIGH MOUNTED STOPLAMP/ CAMERA/LED
HORN RELAY
LEFT LAMP ASSEMBLY
LEFT REAR LAMP ASSEMBLY
MICRO BODY CONTROL MODULE (BCM)
NCA WIRE
POWER SLIDING REAR WINDOW OPEN RELAY
POWER STEERING CONTROL MODULE (PSCM)
POWERTRAIN CONTROL MODULE (PCM)
PTC BANK 3 RELAY
REAR PARKING AID CAMERA
REAR WINDOW DEFROST RELAY
RED WIRE
REDUCTANT HEATER RELAY
REMOTE TRAILER CAMERA
RIGHT LAMP ASSEMBLY
RIGHT REAR LAMP ASSEMBLY
RUN/ START (FET)
RUN/ START RELAY
SNOW PLOW PREP
STARTER RELAY
STEERING EFFORT CONTROL MODULE (SECM)
TO FUSE 32 (DIAGRAM 2 OF 9)
TO FUSE 32 (DIAGRAM 6 OF 9)
TO FUSE 34 (DIAGRAM 5 OF 9)
TO FUSE 38 (DIAGRAM 4 OF 9)
TO LF HI BEAM 2 (FET) (DIAGRAM 6 OF 9)
TO LR TURN LPS (FET) (DIAGRAM 6 OF 9)
TO POWER POINT RELAY 5 (DIAGRAM 3 OF 9)
TRAILER CAMERA/ TRAILER TPMS CONNECTOR
TRAILER TIRE PRESSURE MONITOR SYSTEM (TPMS) MODULE
TRAILER TOW BATTERY CHARGE RELAY
TRAILER TOW LH STOP/ TURN RELAY
TRAILER TOW MODULE
TRAILER TOW PARK LAMP RELAY
TRAILER TOW RH STOP/ TURN RELAY
TRANSFER CASE CONTROL MODULE (TCCM)
TRANSMISSION CONTROL MODULE (TCM)
VIO/GRY WIRE
W/ BLIS W/O LED LAMPS
W/ BLIS, LED LAMPS
WHT WIRE
WHT/VIO WIRE
WIDE FRAME NARROW FRAME 6.2L FLEX FUEL, 7.3L 6.7L TURBO DIESEL
WIPER MOTOR RELAY
YEL/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (2 of 9) -> TRAILER TOW LH STOP/ TURN RELAY
Wiring diagram trailer tow lh stop/ turn relay (2 of 2)
BATTERY JUNCTION BOX (BJB)
BLK/VIO WIRE
BLU WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRAKE PEDAL POSITION (BPP) SWITCH
BRN WIRE
ENG LP (FET)
FUSE 25
GRN WIRE
GRN/BLU WIRE
GRY/BRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LOAD SHED RELAY (FET)
MICRO -
ORG/ WIRE
RED WIRE
SNOW PLOW PREP
TRAILER TOW CONNECTOR
TRAILER TOW LH STOP/ TURN RELAY
TRAILER TOW RH STOP/ TURN RELAY
TT LR STOP/TURN RELAY (FET)
TT PARK RELAY (FET)
TT RR STOP/TURN RELAY (FET)
VIO/BRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/ TRAILER TOW MODULE
W/O TRAILER TOW MODULE
WHT WIRE
WHT/RED WIRE
WIDE FRAME
YEL WIRE
YEL/BLU WIRE
Go to component -> Trailer/camper adapter circuit (2 of 3) -> TRAILER TOW LH STOP/ TURN RELAY
