Ford F-250 XIV (2017-2024) park aid sensors power rear Wiring diagram
This page shows the only wiring diagram for the component.park aid sensors power rear, which is found in the car Ford F-250 XIV (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park aid sensors power rear (1 of 1)
BLK/VIO WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 17
GRN/WHT WIRE
HOT W/ RUN/START RELAY ENERGIZED
LEFT INNER PARKING AID SENSOR
LEFT OUTER PARKING AID SENSOR
LR OUTER SNS
PARK AID SENSORS POWER REAR
PARKING AID MODULE (PAM)
POWER DISTRIBUTION SYSTEM
PWR 2 3
REAR SENSORS GROUND
RIGHT INNER PARKING AID SENSOR
RIGHT OUTER PARKING AID SENSOR
RR INNER SNS
RR OUTER SNS LR INNER SNS
SOLID STATE
WHT WIRE
WHT/ORG WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Parking assistant circuit -> PARK AID SENSORS POWER REAR
