Ford F-250 XIV (2017-2024) lin 04 Wiring diagrams
This page contains all the electrical diagrams for the component. lin 04, in which he is found in the car Ford F-250 XIV (2017-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram lin 04 (1 of 2)
10-WAY
8 WAY
A/C CLUTCH RELAY
AC OUTLET 1
AC OUTLET 2 (IF EQUIPPED)
AC-A
AC-B
ALT SENSE FUSE 45
ALT SENSE FUSE 71
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
CONSTANT VACUUM HUBLOCK (CVH) SOLENOID
DC/AC INVERTER MODULE (RIGHT REAR OF CAB)
DRIVER SEAT MODULE (DSM)
DRIVER SIDE FRONT SEAT CONTROL SWITCH
FROM FUSE 36 (DIAGRAM 2 OF 9)
FRONT CONTROLS INTERFACE MODULE (FCIM)
FUSE 12
FUSE 33
FUSE 38
FUSE 39
FUSE 40
FUSE 41
FUSE 44
FUSE 46
FUSE 47
FUSE 48
FUSE 58
FUSE 6
FUSE 65
FUSE 75
FUSE 8
FUSE 9
GCC COOLING RELAY
GENERATOR
GENERIC FUNCTION MODULE
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/RED WIRE
HEATED WIPER PARK RELAY
HOT
LED
LIN 04
NEUT
ORG/GRN WIRE
ORG/WHT WIRE
PASSENGER SIDE FRONT SEAT CONTROL SWITCH
POWER RUNNING BOARD (PRB) MODULE
POWER STEERING CONTROL MODULE
PTC BANK 1 RELAY
PTC BANK 2 RELAY
REAR HEATED SEAT MODULE
RED WIRE
SECONDARY GENERATOR
SPOT LAMP MODULE (SLM)
SUPER CAB, CREW CAB
TAILGATE SOLENOID RELAY
TELESCOPING EXTERIOR REAR VIEW MIRROR EXTEND RELAY
TELESCOPING EXTERIOR REAR VIEW MIRROR RETRACT RELAY
TO POWER POINT RELAY 2 (DIAGRAM 3 OF 9)
TRAILER BRAKE CONTROL MODULE (TBM)
TRANSMISSION CONTROL MODULE (TCM)
VIO WIRE
VIO/GRN WIRE
VIO/RED WIRE
W/ DUAL GENERATORS
W/ MEMORY
W/ TRAILER BRAKE CONTROL MODULE
W/O TRAILER BRAKE CONTROL MODULE
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Power distribution circuit (4 of 9) -> LIN 04
Wiring diagram lin 04 (2 of 2)
6.7L TURBO DIESEL
7.3L, 6.2L FLEX FUEL
BLK/VIO WIRE
BLU/GRY WIRE
BLU/WHT (OR BLU/GRY) WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BODY CONTROL MODULE (BCM) (RIGHT KICK PANEL)
BRAKE SHIFT INTERLOCK
BTSI
CHILD LOCK RELAY
DOUBLE/ AUX LOCK RELAY
ENG SW
FROM BODY CONTROL MODULE (BCM) (DIAGRAM 5 OF 9)
FROM DC/AC INVERTER MODULE (DIAGRAM 4 OF 9)
FROM FUSE 16 (DIAGRAM 5 OF 9)
FROM FUSE 3 (DIAGRAM 5 OF 9)
FROM FUSE 34 (DIAGRAM 5 OF 9)
GRN/RED WIRE
HIGH MOUNTED STOPLAMP/ CAMERA/LED
IGN
IGNITION SWITCH
IMAGE PROCESSING MODULE B (IPMB)
KEY IN
LIN 04
MICRO -
NCA WIRE
NOT USED
OFF
OFF IGN
POWERTRAIN CONTROL MODULE (PCM)
PUSH BUTTON START IGNITION SWITCH
REAR PARKING AID CAMERA
RUN WIRE
START BUTTON (FET)
START STOP
START/ STOP 1 (ACTIVE HIGH)
START/ STOP 2 (ACTIVE LOW)
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
W/ PUSH BUTTON START W/O PUSH BUTTON START W/ FIXED CAMERA W/ LOOSE CAMERA
W/O 360 CAMERA
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/ORG WIRE
Go to component -> Power distribution circuit (7 of 9) -> LIN 04
