Ford F-250 XIV (2017-2024) high mounted stop lamp/ camera/led Wiring diagrams
This page contains all the electrical diagrams for the component. high mounted stop lamp/ camera/led, in which he is found in the car Ford F-250 XIV (2017-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram high mounted stop lamp/ camera/led (1 of 2)
BATTERY JUNCTION BOX (BJB)
BLK/VIO WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
CHMSL VIDEO -
COAX
COMPUTER DATA LINES SYSTEM
FRONT PARKING AID CAMERA
FRONT/360 CAMERA ENABLE
FUSE 36
FUSE 51
FVC PWR/LVD OUT
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
HIGH MOUNTED STOP LAMP/ CAMERA/LED
HOT W/ RUN/START RELAY ENERGIZED
IMAGE PROCESSING MODULE B (IPMB)
IPMB VIDEO IN -
IPMB VIDEO OUT -
LANE KEEPING SYSTEM/ CAMERA SELECTION SWITCH
LEFT EXTERIOR MIRROR CAMERA
LH PWR/LVD OUT
NCA WIRE
POWER DISTRIBUTION SYSTEM
PWR/LVD OUT
REAR PARKING AID CAMERA
REAR VIDEO -
REMOTE TRAILER CAMERA
RH PWR/LVD OUT
RIGHT EXTERIOR MIRROR CAMERA
RVC PWR/LVD OUT
SHIELD
SYNC MODULE (APIM) (CENTER OF DASH)
TRAILER CAMERA/ TRAILER TPMS CONNECTOR
TRAILER TIRE PRESSURE MONITOR SYSTEM (TPMS) MODULE
VIDEO+
VIO/BRN WIRE
VIO/GRY WIRE
VPWR
WHT WIRE
WHT/GRN WIRE
Go to component -> All around vision camera circuit, w/ 360 view -> HIGH MOUNTED STOP LAMP/ CAMERA/LED
Wiring diagram high mounted stop lamp/ camera/led (2 of 2)
BATTERY JUNCTION BOX (BJB)
BLK/VIO WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/GRN WIRE
CHMSL/REMOTE VIDEO +
COMPUTER DATA LINES SYSTEM
CUSTOMER ACCESS, OPTIONAL TRAILER CAMERA EXTENSIONS
FUSE 36
FUSE 51
GND FRT/360 CAMERA ENABLE
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
HIGH MOUNTED STOP LAMP/ CAMERA/LED
HOT W/ RUN/START RELAY ENERGIZED
IMAGE PROCESSING MODULE B (IPMB)
IPMB VIDEO IN -
IPMB VIDEO OUT -
LANE KEEPING SYSTEM/ CAMERA SELECTION SWITCH
NCA WIRE
POWER DISTRIBUTION SYSTEM
REAR PARKING AID CAMERA
REAR VIDEO -
REMOTE TRAILER CAMERA
SHIELD
SHIELD SHIELD
SYNC MODULE (APIM) (CENTER OF DASH)
VIDEO+
VIO/BRN WIRE
VIO/GRY WIRE
VPWR
WHT WIRE
WHT/GRN WIRE
Go to component -> All around vision camera circuit, w/o 360 view -> HIGH MOUNTED STOP LAMP/ CAMERA/LED
