Ford F-250 XIV (2017-2024) fuse 09 Wiring diagram
This page shows the only wiring diagram for the component.fuse 09, which is found in the car Ford F-250 XIV (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 09 (1 of 1)
ANT
BATTERY JUNCTION BOX (BJB)
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN/VIO WIRE
CAN (+)
COMPUTER DATA LINES SYSTEM
CREW CAB/SUPER CAB
ECU DRV (PCM WAKE UP) (FET)
FUSE 09
FUSE 2
GRN/BLU WIRE
GRN/ORG WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HALF BRIDGE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
INTRUSION SENSOR
KEYLESS ENTRY REAR ANTENNA
LIN 1
LIN 3
MICRO -
PASSIVE ANTI-THEFT SYSTEM (PATS) CENTER ANTENNA
PASSIVE ANTI-THEFT SYSTEM (PATS) REAR ANTENNA
PASSIVE ANTI-THEFT SYSTEM (PATS) TRANSCEIVER
PCM WAKE
PROTECT 1 ANTENNA HIGH (HB)
PROTECT 1 ANTENNA LOW (HB)
PROTECT 2 ANTENNA HIGH (HB)
PROTECT 2 ANTENNA LOW (HB)
PWR GND
RED WIRE
VIO/ORG WIRE
W/ CONSOLE
W/O CONSOLE
WHT WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Passive anti-theft circuit -> FUSE 09
