Ford F-250 XIV (2017-2024) customer access Wiring diagram
This page shows the only wiring diagram for the component.customer access, which is found in the car Ford F-250 XIV (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram customer access (1 of 1)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
CUSTOMER ACCESS
FROM BODY CONTROL MODULE (BCM) (DIAGRAM 5 OF 9)
FROM HIGH CURRENT BATTERY JUNCTION BOX (BJB) (DIAGRAM 1 OF 9)
FUSE 1
FUSE 10
FUSE 2
FUSE 3
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GRN/BRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
ORG/ WIRE
RED WIRE
UPFITTER PTO RELAY
UPFITTER RELAY 1
UPFITTER RELAY 2
UPFITTER RELAY 3
UPFITTER RELAY 4
UPFITTER RELAY 5
UPFITTER RELAY 6
UPFITTER RELAY BOX
UPFITTER RUN/ START RELAY
UPFITTER SWITCH (CENTER FRONT OF ROOF)
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT/RED WIRE
YEL WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (8 of 9) -> CUSTOMER ACCESS
