Ford F-250 XIV (2017-2024) blk/yel Wiring diagrams
This page contains all the electrical diagrams for the component. blk/yel, in which he is found in the car Ford F-250 XIV (2017-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
blk/yel wiring diagram (1 of 51)
AUTO DIMMING INTERIOR MIRROR
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BODY CONTROL MODULE (BCM)
FUSE 1
FUSE 27
GRN/BRN WIRE
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
LANE KEEPING
MICRO -
NCA WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
REV INHIBIT
REV LPS (FET)
RUN/START
W/ AUTOMATIC WINDSHIELD WIPERS W/O AUTOMATIC WINDSHIELD WIPERS 2
YEL WIRE
Go to component -> Electrochromic mirror circuit -> BLK/YEL WIRE
blk/yel wiring diagram (2 of 51)
6.7L TURBO DIESEL
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
CNG PREP CONNECTOR
CUSTOMER ACCESS (TAPED TO HARNESS
ELECTRIC BOOSTER HEATER
EXCEPT 6.7L TURBO DIESEL 6.7L TURBO DIESEL
EXCEPT 6.7L TURBO DIESEL W/ DUAL BATTERY
EXCEPT 6.7L TURBO DIESEL W/ SINGLE BATTERY
FUEL PUMP CONTROL MODULE
FUEL PUMP, SENDER UNIT SHIELD
NCA WIRE
NOX 11 SENSOR MODULE
NOX 12 SENSOR MODULE
POWERTRAIN CONTROL MODULE (PCM)
REDUCTANT PRESSURE LINE HEATER ASSEMBLY
REDUCTANT PUMP ASSEMBLY
REDUCTANT PUMP CONTROL MODULE
REDUCTANT QUALITY MODULE
SECONDARY BATTERY
TRANSMISSION CONTROL MODULE (TCM)
W/ 175.5 INCH WB
WATER IN-FUEL SENSOR
WIDE FRAME
WINDSHIELD WASHER PUMP MOTOR
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (1 of 8) -> BLK/YEL WIRE
blk/yel wiring diagram (3 of 51)
AIR CONDITIONING (A/C) COMPRESSOR CLUTCH FIELD COIL
ANTI-THEFT HOOD SWITCH
AUX COOLING FAN MOTOR
BLK WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR CONTROL MODULE
BLOWER RELAY
CRUISE CONTROL MODULE (CCM)
ENGINE COMPARTMENT LAMP
GENERIC FUNCTION MODULE (GFM)
GLOW PLUG CONTROL MODULE (GPCM)
HALOGEN W/ 4 HEADLAMP SYSTEM
HEATED WIPER PARK
HEATER WIPER PARK
HORN
LEFT FOG LAMP
LEFT FRONT PARK/TURN LAMP
LEFT FRONT SIDE LAMP
LEFT HEADLAMP
LEFT LOWER HEADLAMP
LEFT UPPER HEADLAMP
MULTI- CONTOUR SEAT RELAY
POWER SLIDING REAR WINDOW CLOSE RELAY
POWER SLIDING REAR WINDOW OPEN RELAY
PTC BANK RELAY 1
PTC BANK RELAY 2
PTC BANK RELAY 3
REDUCTANT HEATED RELAY
RIGHT FOG LAMP
RIGHT FRONT PARK/TURN LAMP
RIGHT FRONT SIDE LAMP
RIGHT HEADLAMP
RIGHT LOWER HEADLAMP
RIGHT UPPER HEADLAMP
TELESCOPING EXTERIOR REAR VIEW MIRROR EXTEND RELAY
TELESCOPING EXTERIOR REAR VIEW MIRROR RETRACT RELAY
TRAILER TOW BACKUP LAMPS RELAY
TRANSFER CASE CONTROL MODULE (TCCM)
W/ ADAPTIVE CRUISE CONTROL
W/ LED
W/O LED
Go to component -> Ground distribution circuit (2 of 8) -> BLK/YEL WIRE
blk/yel wiring diagram (4 of 51)
AUTO DIMMING INTERIOR MIRROR
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
DC/AC INVERTER MODULE
DOME LAMP
IMAGE PROCESSING MODULE (IPMA)
INTRUSION SENSOR
LEFT REAR INTERIOR LAMP
LEFT VANITY MIRROR LAMP
NCA WIRE
OVERHEAD CONSOLE
RADIO TRANSCEIVER MODULE (RTM)
REAR INTERIOR LAMP
REAR POWER SLIDING WINDOW SWITCH
RIGHT REAR DOOR AJAR SWITCH
RIGHT REAR DOOR WINDOW CONTROL SWITCH
RIGHT REAR INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP
RIGHT REAR INTERIOR LAMP
RIGHT VANITY MIRROR LAMP
TELEMATIC CONTROL UNIT (TCU) MODULE
W/ AMBIENT LIGHTING
W/ OVERHEAD CONSOLE
W/ VISTA ROOF
W/O OVERHEAD CONSOLE
Go to component -> Ground distribution circuit (5 of 8) -> BLK/YEL WIRE
blk/yel wiring diagram (5 of 51)
AUDIO CONTROL MODULE (ACM)
AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
CENTER ROOF MARKER LAMP
CLOCKSPRING
CREW CAB
DATA LINK CONNECTOR (DLC)
GATEWAY MODULE
HIGH MOUNTED STOPLAMP
HIGH MOUNTED STOPLAMP/ CAMERA/LED
HIGH MOUNTED STOPLAMP/LED
HORN SWITCH
LEFT CENTER ROOF MARKER LAMP
LEFT REAR DOOR AJAR SWITCH
LEFT REAR DOOR WINDOW CONTROL SWITCH
LEFT REAR INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP
LEFT REAR SEAT BACK HEATER
LEFT ROOF MARKER LAMP
LEFT STEERING WHEEL SWITCH
NCA WIRE
REAR HEATED SEAT MODULE
REAR WINDOW DEFROST GRID
REMOTE TAILGATE RELEASE SWITCH
RIGHT CENTER ROOF MARKER LAMP
RIGHT REAR SEAT BACK HEATER
RIGHT ROOF MARKER LAMP
RIGHT STEERING WHEEL SWITCH
ROOF OPENING PANEL MODULE
STEERING COLUMN CONTROL MODULE (SCCM)
SUNSHADE MODULE
SUPER CAB
SYNC MODULE (APIM)
TAILGATE RELEASE SWITCH
W/ ADAPTIVE STEERING W/O ADAPTIVE STEERING W/ CRUISE CONTROL W/O CRUISE CONTROL
W/ REAR HEATED SEATS
W/ ROOF OPENING PANEL
W/ SYNC 3
W/O LED
Go to component -> Ground distribution circuit (6 of 8) -> BLK/YEL WIRE
blk/yel wiring diagram (6 of 51)
6.7L TURBO DIESEL
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/GRY WIRE
BRN WIRE
CLOCKSPRING/ STEERING ANGLE SENSOR MODULE (SASM)
ELECTRONIC LOCKING DIFFERENTIAL FIELD COIL
FUEL PUMP CONTROL MODULE
FUEL PUMP, SENDER UNIT SHIELD
LEFT REAR LAMP
LEFT STEERING WHEEL SWITCH
NCA WIRE
NOX 11 SENSOR MODULE
NOX 12 SENSOR MODULE
POWER STEERING CONTROL MODULE (PSCM)
REDUCTANT PRESSURE LINE HEATER ASSEMBLY
REDUCTANT PUMP ASSEMBLY
REDUCTANT PUMP CONTROL MODULE
REDUCTANT QUALITY MODULE
RIGHT REAR LAMP
STEERING EFFORT CONTROL MODULE (SECM)
W/ ADAPTIVE
W/ AFT DUAL FUEL TANKS
W/ EXTENSION HARNESS
WATER IN-FUEL SENSOR
Go to component -> Ground distribution circuit (8 of 8) -> BLK/YEL WIRE
blk/yel wiring diagram (7 of 51)
A/D CHANNEL 1
A/D RETURN
AAT
AMBIENT AIR TEMPERATURE (AAT) SENSOR
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CLOCKSPRING
CLOCKSPRING/ STEERING ANGLE SENSOR MODULE (SASM)
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
CREW CAB
DIESEL
DOWN
EOP SW
GASOLINE
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
LEFT
LEFT FRONT DOOR AJAR SWITCH
LEFT REAR DOOR AJAR SWITCH
LEFT STEERING WHEEL SWITCH
MULTI- FUNCTION SWITCH
MUTE
NCA WIRE
OIL PRESSURE SWITCH
PANEL)
POWERTRAIN CONTROL MODULE (PCM)
RIGHT
RIGHT EXTERIOR MIRROR
RIGHT FRONT DOOR AJAR SWITCH
RIGHT REAR DOOR AJAR SWITCH
RIGHT STEERING WHEEL SWITCH
SEEK L
SEEK R
SIG RTN
STEERING COLUMN CONTROL MODULE (SCCM)
STEERING EFFORT CONTROL MODULE (SECM)
SUPER CAB
SUPER CAB, CREW CAB
SYSTEM
VBATT
VOL (-)
W/ ADAPTIVE STEERING
W/ POWER MIRROR
W/O ADAPTIVE STEERING
W/O AMBIENT LIGHTING
W/O CRUISE CONTROL W/ CRUISE CONTROL
W/O POWER MIRROR
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> BLK/YEL WIRE
blk/yel wiring diagram (8 of 51)
BACK LTG (FET)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/YEL WIRE
BODY CONTROL MODULE (BCM)
BRN/GRN WIRE
COURTESY
DEMAND
FUSE 2
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
ILLUM
INT LTG (FET)
M/ROOF CLOSE
M/ROOF OPEN
M/ROOF TILT
MICRO -
OVERHEAD CONSOLE
POWER TOPS SYSTEM
RED WIRE
SHADE CLOSE
SHADE OPEN
SUPER CAB, CREW CAB
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
WHT/BLU WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Overhead console circuit -> BLK/YEL WIRE
blk/yel wiring diagram (9 of 51)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DRIVER DOOR MODULE (DDM)
EXTERIOR
FUSE 23
FUSE 26
FUSE 6
GRN WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
LEDS
LEFT EXTERIOR MIRROR
LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
LEFT FRONT DOOR LOCK SWITCH
LIGHTS)
MASTER WINDOW CONTROL SWITCH
MICRO -
MIRR FOLD IN
MIRR FOLD OUT
MIRR LEFT
MIRR RTN
MIRR UP
MIRROR SENSOR/ BLIS GND BLIS IND
PARK
PUDDLE LAMP
PUDDLE LIGHT
RTN
RTN LIN
SIDE TURN IND
SPOT IND
SUPER CAB, CREW CAB
SYSTEM
VBATT
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Power mirrors circuit (1 of 2) -> BLK/YEL WIRE
blk/yel wiring diagram (10 of 51)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
ENGINE CONTROLS SYSTEM
EXTERIOR
FUSE 65
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
LEDS
LIGHTS)
MICRO -
MIRR FOLD IN
MIRR FOLD OUT
MIRR LEFT
MIRR RTN
MIRR UP
MIRROR SENSOR/ BLIS GND BLIS IND
PARK
PASSENGER DOOR MODULE (PDM)
PUDDLE LAMP
PUDDLE LIGHT
RIGHT EXTERIOR MIRROR
RIGHT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
SIDE TURN IND
SPOT IND
SYSTEM
TELE IN
TELE OUT
TELESCOPING EXTERIOR REAR VIEW MIRROR EXTEND RELAY
TELESCOPING EXTERIOR REAR VIEW MIRROR RETRACT RELAY
TELESCOPING EXTERIOR REAR VIEW MIRROR SWITCH
VBATT
VIO/BRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
WHT/BLU WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Power mirrors circuit (2 of 2) -> BLK/YEL WIRE
