Climate control seats circuit for Ford F-150 XIV (2020-2024)

BATTERY JUNCTION BOX (BJB) BLK/BLU WIRE BLU WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/VIO WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DBCKBLWCTL DBLWR+ DCSHCBLWCTL DRIVER FRONT SEAT MODULE (DSM) DRV HEATER FEED DRV ST NTC SENSE FUSE 38 GRN/BRN WIRE GRN/RED WIRE GRY/BLU WIRE GRY/ORG WIRE HOT AT ALL TIMES LEFT FRONT SEAT CUSHION BLOWER MOTOR MS CAN + NCA WIRE PASS HEATER FEED PASS ST NTC SENSE PBCKBLWCTL PBLWR+ PCSHCBLWCTL RIGHT FRONT SEAT CUSHION BLOWER MOTOR SIGRTN VBATT VIO WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT/BRN WIRE WHT/ORG WIRE YEL/BLU WIRE

BLU WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRN/GRN WIRE BRN/VIO WIRE BRN/YEL WIRE GRN/BRN WIRE GRY/BLU WIRE GRY/ORG WIRE LEFT FRONT SEAT BACKREST BLOWER MOTOR LEFT FRONT SEAT BACKREST HEATER MAT LEFT FRONT SEAT CUSHION HEATER MAT NCA WIRE RIGHT FRONT SEAT BACKREST BLOWER MOTOR RIGHT FRONT SEAT BACKREST HEATER MAT RIGHT FRONT SEAT CUSHION HEATER MAT VIO WIRE VIO/GRY WIRE VIO/WHT WIRE WHT/ORG WIRE YEL/BLU WIRE YEL/GRN WIRE
