Navigation circuit, 8 speakers for Ford F-150 XIV (2020-2024)

AM/FM AUDIO CONTROL PANEL AUDIO FRONT CONTROL MODULE (ACM) AUDIO UNIT ANTENNA AUTOMOTIVE AUDIO BUS (AAB) CABLE BLK WIRE BLK/GRY WIRE BLK/VIO WIRE BODY CONTROL MODULE (BCM) COMPUTER DATA LINES SYSTEM DRDL TX + FUSE 15 FUSE 28 FUSE 32 GPS/ SATELLITE RADIO/ SECONDARY CELLULAR ANTENNA GRN/BLU WIRE GRN/RED WIRE GRY/VIO WIRE HOT AT ALL TIMES LEFT A-PILLAR TWEETER SPEAKER LF SPKR MULTI-FUNCTION DISPLAY 8 NCA WIRE RF SPKR SATELLITE SPLITTER (W/ SATELLITE RADIO) VBATT VIO/GRY WIRE VIO/RED WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/RED WIRE WHT/VIO WIRE YEL/ORG WIRE

AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE (BEHIND LEFT REAR SEAT) AUTOMOTIVE AUDIO BUS (AAB) CABLE BLK WIRE BLK/VIO WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE CENTER INSTRUMENT PANEL SPEAKER COMPUTER DATA LINES SYSTEM CREW CAB ENABLE/CLIP DETECT GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/VIO WIRE GRY/YEL WIRE IP SPKR + LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LF SPKR LR SPKR NCA WIRE RF SPKR RR SPKR SUBWOOFER SPEAKER SUPER CAB VBATT VIO/GRY WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/RED WIRE WHT/VIO WIRE YEL/ORG WIRE YEL/VIO WIRE

ALERT OUT + BLK WIRE BLU WIRE BLU/GRY WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CREW CAB DISPLAY DISPLAY NTSC - DISPLAY SHIELD DRDL TX + GPS GRN/BLU WIRE GRY/ORG WIRE GRY/VIO WIRE MIC - MIC IN - NAVIGATION SYSTEM NCA WIRE PWR REAR CAMERA CIRCUIT RIGHT A-PILLAR TWEETER SPEAKER RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER SHIELD STEREO OUT L + STEREO OUT R + SUPER CAB SYNC MODULE (APIM) (CENTER OF DASH) V BATT VIO/GRN WIRE VIO/GRY WIRE VOICE MICROPHONE WHT/GRN WIRE WHT/ORG WIRE WHT/RED WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE

A/D CHANNEL 1 A/D CHANNEL 2 A/D CHANNEL 3 A/D RETURN ALERT IN + AUDIO FRONT CONTROL MODULE (ACM) BLK/GRY WIRE BLU WIRE BLU/GRY WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DETECT DM GND DM PWR ENABLE/CLIP ETHERNET GRY/BLU WIRE GRY/ORG WIRE ILLUM LVDS (LOW-VOLTAGE DIFFERENTIAL SIGNALING) COAXIAL CABLE MEDIA HUB MULTI-FUNCTION DISPLAY 12 MULTI-FUNCTION DISPLAY 8 NCA WIRE PWR SDL H SDL L STEERING EFFORT CONTROL MODULE (SECM) STEREO IN L - STEREO IN R+ SYNC MODULE (APIM) (CENTER OF DASH) TPA 1 + TPA 2 + TPA+ USB CABLE USB D- USB GND USB VBUS VIO/GRN WIRE VIO/GRY WIRE W/ FLOOR MOUNTED CONSOLE W/O FLOOR MOUNTED CONSOLE WHT/BLU WIRE WHT/BRN WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/VIO WIRE

A/D CHANNEL 1 A/D CHANNEL 2 A/D CHANNEL 3 A/D RETURN BLK/BLU WIRE BLK/GRY WIRE BODY CONTROL MODULE (BCM) CLOCKSPRING COMPUTER DATA LINES SYSTEM DISPLAY UNIT DM GND DM PWR FUSE 13 FUSE 29 GRN/ORG WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES ILLUM LEFT STEERING WHEEL SWITCH LVDS (LOW-VOLTAGE DIFFERENTIAL SIGNALING) COAXIAL CABLE MULTI-FUNCTION DISPLAY 12 MULTI-FUNCTION DISPLAY 8 NCA WIRE RIGHT STEERING WHEEL SWITCH STEERING COLUMN CONTROL MODULE (SCCM) TPA 1 + TPA 2 + TPA+ VBATT W/ ADAPTIVE STEERING W/O ADAPTIVE STEERING
