Car Wiring Diagrams for Pedestrian alert circuit for Ford F-150 XIV (2020-2024)

Pedestrian alert circuit

Car Wiring Diagrams for F-150 Ford XIV (2020-2024): Pedestrian alert circuit
Get lifetime access to Ford F-150 XIV (2020-2024)

BATTERY JUNCTION BOX (BCMC) BLK/VIO WIRE BLU WIRE COMPUTER DATA LINES SYSTEM FRONT PEDESTRIAN ALERT SYSTEM SPEAKER FRONT SPEAKER FUSE 170 GRN/ORG WIRE GRY/YEL WIRE HOT W/ CONTACTOR RELAY ENERGIZED PEDESTRIAN ALERT CONTROL MODULE (PACM) VIO/WHT WIRE VPWR WHT WIRE
