Ford F-150 XIV (2020-2024) w/o tailgate power release, close Wiring diagrams
This page contains all the electrical diagrams for the component. w/o tailgate power release, close, in which he is found in the car Ford F-150 XIV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/o tailgate power release, close (1 of 2)
AUXILIARY BATTERY 1
AUXILIARY BATTERY BOX
BATTERY
BATTERY MONITORING SENSOR
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER
GRN WIRE
GRN/RED WIRE
LEFT REAR BED MARKER LAMP
LEFT REAR LAMP ASSEMBLY
LEFT TRUCK BED LAMP
NCA WIRE
RAPTOR
REAR GATE TRUNK MODULE (RGTM)
RIGHT REAR BED MARKER LAMP
RIGHT REAR LAMP ASSEMBLY
RIGHT TRUCK BED LAMP
TAILGATE RELEASE ACTUATOR
TAILGATE RELEASE SWITCH
TRAILER ASSIST LAMP
TRUCK BED LAMP SWITCH
W/ TAILGATE POWER RELEASE, CLOSE
W/O TAILGATE POWER RELEASE, CLOSE
YEL WIRE
Go to component -> Ground distribution circuit (10 of 10) -> W/O TAILGATE POWER RELEASE, CLOSE
Wiring diagram w/o tailgate power release, close (2 of 2)
BATTERY ENERGY CONTROL MODULE (BECM)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
EXHAUST HEAT EXCHANGER VALVE
FUEL PUMP ASSEMBLY SHIELD
FUEL PUMP CONTROL MODULE
LEFT EXHAUST TAILPIPE ACTUATOR
LEFT REAR LAMP ASSEMBLY
LEFT TRUCK BED LAMP
NCA WIRE
RAPTOR
REAR GATE TRUNK MODULE (RGTM)
RIGHT EXHAUST TAILPIPE ACTUATOR
RIGHT REAR LAMP ASSEMBLY
RIGHT TRUCK BED LAMP
TAILGATE RELEASE ACTUATOR
TAILGATE RELEASE SWITCH
TRAILER ASSIST LAMP
TRUCK BED LAMP SWITCH
VEHICLE DYNAMICS CONTROL MODULE (VDM)
W/ INCANDESCENT BASE TAILLAMPS
W/ INCANDESCENT BLIS TAILLAMPS W/O SMART HITCH
W/ LED BLIS TAILLAMPS, SMART HITCH
W/ TAILGATE POWER RELEASE, CLOSE
W/ TAILGATE POWER RELEASE, CLOSE W/O TAILGATE POWER RELEASE, CLOSE
W/O TAILGATE POWER RELEASE, CLOSE
YEL WIRE
Go to component -> Ground distribution circuit (9 of 10) -> W/O TAILGATE POWER RELEASE, CLOSE
