Ford F-150 XIV (2020-2024) w/ tailgate power release, close w/o tailgate power release, close wiring diagram
This page shows the only wiring diagram for the component.w/ tailgate power release, close w/o tailgate power release, close, which is found in the car Ford F-150 XIV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
w/ tailgate power release, close w/o tailgate power release, close wiring diagram (1 of 1)
BATTERY ENERGY CONTROL MODULE (BECM)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
EXHAUST HEAT EXCHANGER VALVE
FUEL PUMP ASSEMBLY SHIELD
FUEL PUMP CONTROL MODULE
LEFT EXHAUST TAILPIPE ACTUATOR
LEFT REAR LAMP ASSEMBLY
LEFT TRUCK BED LAMP
NCA WIRE
RAPTOR
REAR GATE TRUNK MODULE (RGTM)
RIGHT EXHAUST TAILPIPE ACTUATOR
RIGHT REAR LAMP ASSEMBLY
RIGHT TRUCK BED LAMP
TAILGATE RELEASE ACTUATOR
TAILGATE RELEASE SWITCH
TRAILER ASSIST LAMP
TRUCK BED LAMP SWITCH
VEHICLE DYNAMICS CONTROL MODULE (VDM)
W/ INCANDESCENT BASE TAILLAMPS
W/ INCANDESCENT BLIS TAILLAMPS W/O SMART HITCH
W/ LED BLIS TAILLAMPS, SMART HITCH
W/ TAILGATE POWER RELEASE, CLOSE
W/ TAILGATE POWER RELEASE, CLOSE W/O TAILGATE POWER RELEASE, CLOSE
W/O TAILGATE POWER RELEASE, CLOSE
YEL WIRE
Go to component -> Ground distribution circuit (9 of 10) -> W/ TAILGATE POWER RELEASE, CLOSE W/O TAILGATE POWER RELEASE, CLOSE
