Ford F-150 XIV (2020-2024) telescope in Wiring diagram
This page shows the only wiring diagram for the component.telescope in, which is found in the car Ford F-150 XIV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram telescope in (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (BCM)
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM)
EXTERIOR MIRROR TELESCOPE SWITCH
FUSE 23
FUSE 26
GRN/ORG WIRE
GRN/WHT WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
ILLUM
LEFT EXTERIOR MIRROR
LEFT FRONT DOOR LOCK CONTROL SWITCH
PASSENGER DOOR MODULE (PDM)
RIGHT EXTERIOR MIRROR
RTN
TELESCOPE EXT
TELESCOPE IN
TELESCOPE OUT
TELESCOPE RTN
VBATT
VIO/ORG WIRE
VIO/WHT WIRE
WHT/RED WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Telescoping mirrors circuit -> TELESCOPE IN
