Ford F-150 XIV (2020-2024) security horn relay Wiring diagram
This page shows the only wiring diagram for the component.security horn relay, which is found in the car Ford F-150 XIV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram security horn relay (1 of 1)
ALL DOOR UNLOCK (FET)
ALL RCM POWER DOOR LOCK (FET) (FET)
AMB LTG (FET)
BACK LTG (FET)
BATTERY SAVER (FET)
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BSI (FET)
CHILD DOOR LOCK (FET)
DEL
DOUBLE LOCK OUTPUT (FET)
DRIVER DOOR UNLOCK (FET)
DRIVER DOOR WINDOW CONTROL SWITCH
ECU DRV (PCM WAKEUP) (FET)
ESCL FUEL PUMP ON (FET) (FET)
EXCEPT SUPER CAB, CREW CAB
FET
FROM BATTERY JUNCTION BOX (BCMC) (DIAGRAM 4 OF 12)
FROM DR LOCK LED STATUS (FET) (DIAGRAM 7 OF 12)
FUSE 6
INT LICENSE LAMP LTG (FET) (FET)
LF DRL LPS (FET)
LF FOG LPS (FET)
LF HI BEAM (FET)
LF LOW BEAM (FET)
LF TURN LAMPS (FET)
LR POS LPS (FET)
LR STOP LP POS LP (FET) (FET)
LR TURN LP (FET)
MICRO -
NOT USED
OCS POWER (FET)
PARK LAMPS (FET)
PUDDLE LAMP (FET)
REAR FOG LPS (FET)
RED WIRE
REVERSE LAMP (FET)
RF DRL RF TURN LP LPS (FET) (FET)
RF FOG LPS (FET)
RF HI BEAM (FET)
RF LOW BEAM (FET)
RR POS
RR STOP POS LP (FET)
RR TURN LPS (FET)
SECURITY HORN RELAY
STOP/ CHMSL (FET)
SUPER CAB, CREW CAB
WHITE LIGHT (FET)
Go to component -> Power distribution circuit (10 of 12) -> SECURITY HORN RELAY
