Ford F-150 XIV (2020-2024) secondary cellular Wiring diagram
This page shows the only wiring diagram for the component.secondary cellular, which is found in the car Ford F-150 XIV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram secondary cellular (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (BCM)
BRN/WHT WIRE
CELLULAR
COMPUTER DATA LINES SYSTEM
ETHERNET
FUSE 8
GPS
GPS/SATELLITE RADIO/ SECONDARY CELLULAR ANTENNA
HOT AT ALL TIMES
NCA WIRE
PRIMARY CELLULAR ANTENNA
SECONDARY CELLULAR
TELEMATIC CONTROL UNIT (TCU) MODULE
VBATT
VIO/WHT WIRE
WHT/ORG WIRE
YEL/RED WIRE
Go to component -> Telematics circuit -> SECONDARY CELLULAR
