Ford F-150 XIV (2020-2024) right passenger seat headrest speaker Wiring diagrams
This page contains all the electrical diagrams for the component. right passenger seat headrest speaker, in which he is found in the car Ford F-150 XIV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right passenger seat headrest speaker (1 of 2)
ALERT OUT +
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
CREW CAB
DISPLAY
DISPLAY NTSC -
DISPLAY SHIELD
DRDL TX +
GPS
GRN/BLU WIRE
GRN/ORG WIRE
GRY/ORG WIRE
GRY/VIO WIRE
LEFT FRONT OVERHEAD SPEAKER
MIC -
MIC IN -
NAVIGATION SYSTEM
NCA WIRE
PWR
REAR CAMERA CIRCUIT
RIGHT A-PILLAR TWEETER SPEAKER
RIGHT DRIVER SEAT HEADREST SPEAKER
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT OVERHEAD SPEAKER
RIGHT PASSENGER SEAT HEADREST SPEAKER
RIGHT REAR DOOR SPEAKER
SHIELD
STEREO OUT L +
STEREO OUT R +
SUPER CAB
SYNC MODULE (APIM) (CENTER OF DASH)
V BATT
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VOICE MICROPHONE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Navigation circuit, 18 speakers (3 of 5) -> RIGHT PASSENGER SEAT HEADREST SPEAKER
