Ford F-150 XIV (2020-2024) rear power sliding window switch Wiring diagram
This page shows the only wiring diagram for the component.rear power sliding window switch, which is found in the car Ford F-150 XIV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear power sliding window switch (1 of 1)
18 SPEAKER SYSTEM
5.0L FLEX FUEL
AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE)
AUTO DIMMING INTERIOR MIRROR
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
CREW CAB
DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER
INTRUSION SENSOR
LEFT REAR DOOR AJAR SWITCH
LEFT REAR DOOR AMBIENT LAMP
LEFT REAR DOOR LATCH
LEFT REAR DOOR WINDOW CONTROL SWITCH
LEFT REAR INTERIOR LAMP
LEFT REAR SEAT BACKREST HEATER MAT
LEFT VANITY MIRROR LAMP
NCA WIRE
OVERHEAD CONSOLE
RAIN SENSOR
REAR HEATED SEAT MODULE
REAR POWER SLIDING WINDOW SWITCH
REAR WINDOW DEFROST GRID
RIGHT REAR INTERIOR LAMP
RIGHT REAR SEAT BACKREST HEATER MAT
RIGHT VANITY MIRROR LAMP
SUPER CAB
VIO WIRE
Go to component -> Ground distribution circuit (7 of 10) -> REAR POWER SLIDING WINDOW SWITCH
