Ford F-150 XIV (2020-2024) power sliding rear window close relay Wiring diagrams
This page contains all the electrical diagrams for the component. power sliding rear window close relay, in which he is found in the car Ford F-150 XIV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram power sliding rear window close relay (1 of 3)
2.7L TURBO
3.3L FLEX FUEL
5.0L FLEX FUEL
AIR CONDITIONING (A/C) CLUTCH, AIR CONDITIONING (A/C) CLUTCH FIELD COIL
AIR CONDITIONING CONTROL MODULE (ACCM)
AUXILIARY BATTERY ISOLATOR
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR CONTROL MODULE
BLOWER MOTOR RELAY
BRN/VIO WIRE
CABIN HEATER COOLANT PUMP
ENGINE COOLANT VALVE ASSEMBLY
ENGINE COOLING FAN RELAY #1
ENGINE COOLING FAN RELAY #3
EXCEPT HYBRID
LEFT HEADLAMP RELAY
MICRO -
PEDESTRIAN ALERT CONTROL MODULE (PACM)
POWER SLIDING REAR WINDOW CLOSE RELAY
POWER SLIDING REAR WINDOW OPEN RELAY
POWERTRAIN CONTROL MODULE (PCM)
REDUCTANT HEATER RELAY
RIGHT HEADLAMP RELAY
TAILGATE RELEASE SOLENOID RELAY
TBCV SMART (FET)
TRAILER TOW BACKUP LAMP RELAY
TRANSFER CASE CONTROL MODULE (TCCM)
TRANSMISSION RELAY
UPFITTER RELAY 1
UPFITTER RELAY 2
UPFITTER RELAY 3
UPFITTER RELAY 4
UPFITTER RELAY 5
UPFITTER RELAY 6
Go to component -> Ground distribution circuit (3 of 10) -> POWER SLIDING REAR WINDOW CLOSE RELAY
Wiring diagram power sliding rear window close relay (2 of 3)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLOWER MOTOR RELAY
BLU/RED WIRE
BOO OUTPUT SMART (FET)
BRN WIRE
FROM FUSE 162 (DIAGRAM 3 OF 12)
FUSE 1
FUSE 125
FUSE 134
FUSE 139
FUSE 3
FUSE 32
FUSE 33
FUSE 34
FUSE 41
FUSE 58
FUSE 67
GRN WIRE
GRN/VIO WIRE
MEDIA BIN POWER POINT 1
MEDIA BIN POWER POINT 2
MICRO -
MULTI- CONTOUR SEAT RELAY
POWER POINT RELAY 1
POWER POINT RELAY 2
POWER SLIDING REAR WINDOW CLOSE RELAY
POWER SLIDING REAR WINDOW OPEN RELAY
REAR CONSOLE POWER POINT
REAR WINDOW DEFROST RELAY
RED WIRE
SEAT POWER POINT
SUPER CAB, CREW CAB
TO BODY CONTROL MODULE (BCM) (DIAGRAM 10 OF 12)
TO UPFITTER RELAY 1 (DIAGRAM 12 OF 12)
TRAILER TOW BACKUP LAMP RELAY
TRANSMISSION RELAY
USB CHARGE PORT
USB CHARGE PORT (CENTER BIN)
USB CHARGE PORT (REAR BACKPANEL)
VIO WIRE
W/ FLOOR MOUNTED CONSOLE
W/O FLOOR MOUNTED CONSOLE
WHT WIRE
WHT/BRN WIRE
YEL WIRE
Go to component -> Power distribution circuit (4 of 12) -> POWER SLIDING REAR WINDOW CLOSE RELAY
Wiring diagram power sliding rear window close relay (3 of 3)
BATTERY JUNCTION BOX (BJB)
BLK/VIO WIRE
BLK/YEL WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
CLOSE
FUSE 2
FUSE 41
GRN WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY DELAY RELAY ENERGIZED
POWER SLIDING REAR WINDOW CLOSE RELAY
POWER SLIDING REAR WINDOW MOTOR
POWER SLIDING REAR WINDOW OPEN RELAY
POWER SLIDING REAR WINDOW SWITCH
VIO/BRN WIRE
VIO/ORG WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Sliding rear window circuit -> POWER SLIDING REAR WINDOW CLOSE RELAY
